Magnum Venus Plastech UltraMAX MVP Installation & Set-Up User Manual
Page 2

h. Attach the ground wire from the gun to the electrical grounding lug on the pump mounting
bracket.
Note:
Check electrical ground to ensure it is installed from the pump mounting bracket to an
earth ground.
i. Remove the catalyst poly tubes from the component box.
j. Cut the ½ inch diameter poly line, with the clamps, to 26 inches long. Clamp one end to the
outlet of the catalyst jug and the other end to the inlet of the catalyst pump. Make sure clamps
are airtight.
k. Connect the ¼-inch poly line to the relief valve on the catalyst manifold assembly and insert
the other end into the hole in the top of the catalyst jug.
l. Connect the ¼-inch poly line to the catalyst recirculation valve on the catalyst manifold, and
insert the other end into the hole in the top of the catalyst jug.
9.
Check all components for damage.
