7/9/2013

BRAKES_FLANGE_SPRING_MANUAL

Page 5 of 5

D. REASSEMBLY

(1)

Replace the piston in the cylinder.

(2)

Make sure the tapped holes in the piston are aligned with corresponding holes in the
cylinder.

(3)

Replace the spacers and springs.

(4)

Replace the pressure plate and screws making sure screws are tightened to uniform
torque based on bolt size and use proper Loctite

®

(or equivalent) compound to assure a

permanent mount.

(5)

Inspect the inside diameter of the bearing in the air cylinder. If Loctite

®

residue is

present, gently scrape and assure that the surface is clean.

(6)

Apply a thin coat of Loctite

®

#609 retainer compound to the inside diameter of the air

cylinder bearing, then slide the air cylinder/bearing sub-assembly over the drive hub.
Applying excessive Loctite

®

will make future disassembly more difficult.

(7)

Make sure that all components are well seated and replace the outer retainer ring.

(8) Reassemble drive disc, friction disc, springs and race section according to reference

drawing using new friction discs, springs and steel drive discs as necessary.

(9) Apply air to the brake.
(10) Replace retainer ring on drive hub and bolt on top plate.
(11)

See “Brake Installation” portion of these instructions for the proper procedure for
reinstalling the brake.



Technical assistance is available by contacting Mach III Clutch, Inc.


Mach III Product Warranty

http://www.machiii.com/Resources/Warranty-Info.asp


Mach III Clutch, Inc.

101 Cummings Drive ● Walton, KY 41094

Toll free 866.291.0849 ● International 859.291.0849 ● Fax 859.655.8362
