TL - 2448 LIGHTING CONTROLLER
Version 0.6
OWNERS MANUAL
12/27/2007
www.lightronics.com
Lightronics Inc. 509 Central Drive Virginia Beach, VA 23454 757 486 3588
TABLE OF CONTENTS
PRODUCT DESCRIPTION 3
DIMENSIONS AND WEIGHT 3
INSTALLATION 3
POWER REQUIREMENTS 3
SIGNAL CONNECTIONS 3
SIGNAL WIRING CONNECTIONS 3
WORK LIGHT 3
CONTROLS AND INDICATORS 4
THE LCD DISPLAY 5
THE MENU SYSTEM 5
SETUP AND PRELIMINARY OPERATIONS 6
CONSOLE RESET 6
CHANNEL ASSIGNMENTS (PATCHING) 6
DEFAULT CHANNEL ASSIGNMENTS 6
PATCH PAGES 6
TO CHANGE THE CURRENT PATCH PAGE 6
ASSIGNING CURRENT PATCH PAGE CHANNELS 6
TO COPY A PATCH PAGE 7
TO RESET THE CURRENT PATCH PAGE 7
MANUAL OPERATION 7
MODES OF OPERATION 7
SCENE RECORDING AND PLAYBACK 8
RECORDING A SCENE 8
SCENE PLAYBACK 8
CHASE FUNCTIONS 8
CHASE RECORDING 9
ASSIGNING SCENES TO CHASE STEPS 9
CHASE PLAYBACK 10
USING CUE LISTS 10
CUE LIST RECORDING 10
INITIAL CUE LIST ASSIGNMENTS 10
VIEWING AND EDITING THE CUE LIST 11
TO ASSIGN SCENES TO A CUE 11
CUE LIST PLAYBACK 11
CONTROLLING MOVING LIGHTS 12
SOFT-PATCHING MOVING LIGHT CHANNELS 12
DEFAULT MOVING LIGHT CHANNELS 12
CREATING MOVING LIGHT SCENES 13
SETTING BASIC SCENE CONDITIONS 13
RECORDING THE SCENE 13
APPLYING SCENE FADE CONTROLS 14
CHANNEL CONFIGURATIONS 14
CONFIG - SETTING THE CHANNEL CONFIGURATION 14
DEFAULT FADE 15
FADE RATE 15
ACTIVATING MOVING LIGHT SCENES 15
MANUAL SCENE ACTIVATION 15
MOVING LIGHT SCENES IN CUE'S OR CHASES 15
TL-2448 WIRELESS OPTION 15
MAINTENANCE AND REPAIR 17
OWNER MAINTENANCE 17
TROUBLESHOOTING 17
OPERATING AND MAINTENANCE ASSISTANCE 17
WARRANTY 18
