TL - 4008 MEMORY CONTROL CONSOLE
Revision 1.4 OWNERS MANUAL 02/17/2005
www.lightronics.com
Lightronics Inc. 509 Central Drive Virginia Beach, VA 23454 757 486 3588
DMX OPERATION
If the DMX option is installed in the TL-4008 then it will transmit both DMX and LMX signals simultaneously.
The DMX-512 connection does NOT provide console power therefore an external power supply (provided with
units having DMX option) must be used.
QUICK START INSTRUCTIONS
The bottom cover of the TL-4008 contains brief instructions for using scenes and chases. The instructions are not
intended as a substitute for this manual and should be viewed as "reminders" for operators who are already
familiar with TL-4008 operation.
MAINTENANCE AND REPAIR
TROUBLESHOOTING
Check that the multiplex cable is not defective.
To simplify troubleshooting - reset the unit to provide a known set of conditions.
Make sure the dimmer address switches are set to the desired channels.
OWNER MAINTENANCE
The best way to prolong the life of your TL-4008 is to keep it dry, cool, clean and covered when not in use.
The unit exterior may be cleaned using a soft cloth dampened with a mild detergent/water mixture or a mild spray-
on type cleaner. DO NOT SPRAY ANY LIQUID directly on the unit. DO NOT IMMERSE the unit in any liquid or
allow liquid to get into the controls. DO NOT USE any solvent based or abrasive cleaners on the unit.
The faders are not cleanable. If you use a cleaner in them – it will remove the lubrication from the sliding
surfaces. Once this happens it is not possible to re-lubricate them.
The white strips above the faders are not covered by the TL-4008 warranty. If you mark on them with any
permanent ink, paint etc. it is likely that you will be unable to remove the markings without damaging the strips.
There are no user serviceable parts in the unit. Service by other than Lightronics authorized agents will void your
warranty.
EXTERNAL POWER SUPPLY INFORMATION
The TL-4008 may be powered by an external supply with the following specifications:
Output Voltage: 13 to 25 Volts AC or DC
Output Current: 400 Milliamps
Connector: 2.1mm female connector
NOTE: If a DC Supply is used – the center pin must be the NEGATIVE voltage.
OPERATING AND MAINTENANCE ASSISTANCE
Dealer and Lightronics Factory personnel can help you with operation or maintenance problems. Please read the
applicable parts of this manual before calling for assistance.
If service is required - contact the dealer from whom you purchased the unit or contact Lightronics, Service
Dept., 509 Central Drive, Virginia Beach, VA 23454 TEL: (757) 486-3588.
