AT SERIES ARCHITECTURAL DIMMER
Revision 0.1 OWNERS MANUAL 08/29/2003
www.lightronics.com
Lightronics Inc. 509 Central Drive Virginia Beach, VA 23454 tel 757 486 3588
PROGRAMMING THE UNIT:
The LED's will alternate between the FUNCTION (channel/preset level and preset fade) and its VALUE (intensity
and fade time). There are 2 digits and 3 buttons to control everything. Press the NEXT button to advance through
each FUNCTION. Press the UP and DOWN buttons to change the VALUE for the alternately displayed
FUNCTION.
Note that the 100% intensity value on the LED display is indicated by "FL" (full).
SYMBOL FUNCTION VALUE
1A Channel 1 Preset A intensity 0-100% intensity
1b Channel 1 Preset B intensity 0-100% intensity
1C Channel 1 Preset C intensity 0-100% intensity
1d Channel 1 Preset D intensity 0-100% intensity
2A Channel 2 Preset A intensity 0-100% intensity
2b Channel 2 Preset B intensity 0-100% intensity
2C Channel 2 Preset C intensity 0-100% intensity
2d Channel 2 Preset D intensity 0-100% intensity
3A Channel 3 Preset A intensity 0-100% intensity
3b Channel 3 Preset B intensity 0-100% intensity
3C Channel 3 Preset C intensity 0-100% intensity
3d Channel 3 Preset D intensity 0-100% intensity
4A Channel 4 Preset A intensity 0-100% intensity
4b Channel 4 Preset B intensity 0-100% intensity
4C Channel 4 Preset C intensity 0-100% intensity
4d Channel 4 Preset D intensity 0-100% intensity
1 Channel 1 Up fade time 1-99 seconds (applied to all presets)
1 Channel 1 Down fade time 1-99 seconds (applied to all presets)
2 Channel 2 Up fade time 1-99 seconds (applied to all presets)
2 Channel 2 Down fade time 1-99 seconds (applied to all presets)
3 Channel 3 Up fade time 1-99 seconds (applied to all presets)
3 Channel 3 Down fade time 1-99 seconds (applied to all presets)
4 Channel 4 Up fade time 1-99 seconds (applied to all presets)
4 Channel 4 Down fade time 1-99 seconds (applied to all presets)
You can STOP HERE, or continue and set the individual up/down fade times. If individual
times do not need to be set then proceed to P2-P4 Channel Input power phase selection.
