CREATING YOUR OWN CUSTOM CHASE PATTERN
The programmable chase pattern is created by setting the intensity for all dimmer channels for each step in the
chase. The chase step is then recorded. This action is then repeated for each additional step to be recorded.
The channel intensities can be set either from the RD-121 front panel as in manual operation or by using a control
console.
TO SAVE A CHASE STEP:
1.
Create the step from a control console or from the front panel of the dimmer itself by activating the
applicable channels. Channel intensities are recorded as either full ON or full OFF. If you want a given
channel to be on for a chase step then the channel must be set to greater than 50 % intensity. Note that the
overall intensity of the whole chase pattern may be set using the menu system.
2.
Press and hold the front panel SELECT button until the front panel display appears as shown below:
Scene ×
Save #01
You will have to hold the button down for about 6 seconds.
3. Push
the UP arrow button. The display will appear as follows:
Chs Stp×
Save #01
This is the display for chase step #1. If you want to record to
another step number - use the UP and DOWN arrow buttons to
make the correct step number appear on the lower display row.
4. Push
SELECT. The display will show the message:
SAVING
NOW !
5.
The chase step has been recorded when the LCD reverts to its normal STATUS DISPLAY.
The above recording process is repeated for each step in the programmable chase pattern. See the section
CONTROLLING CHASER CHARACTERISTICS for information about how the chase can be made to appear
when activated.
