ODiSI A10 and A50
LT_DS_ODiSIA Rev 007 03/06/2013
PARAMETER
SPECIFICATION
UNITS
Performance
Model
A10
A50
Maximum Sensing Length
10
50
meters
Acquisition Rate
1
5
2.5
Hz
Minimum Sensor Spacing
0.4
mm
Minimum Gage Length
2
1
mm
Wavelength Accuracy
3
1.5
pm
Strain:
Range
± 13,000
µStrain
Single-scan repeatability
1,4,5
± 2
µStrain
Temperature:
Range
6
-50 to 300
°C
Single-scan repeatability
1,4,5
± 0.2
°C
Physical
Dimensions
14 x 12.5 x 6.75
(36 x 32 x 17)
in (cm)
Weight
17.5
(8)
lb (kg)
Power Consumption
50
W
CLASS 1 LASER PRODUCT
1
For the default measurement range of ±1,250 µStrain or ±200 °C; see Page 3 for detailed timing information
2
Minimum gage length is achievable using the largest measurement range, having a single-scan repeatability of ±17.0 µStrain or
±2.0 °C
3
Accuracy maintained by an internal NIST-traceable HCN gas cell
4
Temperature and strain measurements are calculated from the spectral shift of scattered laser light. Using the default conversion
coefficients of 1 GHz = 0.8 °C = 6.58 µStrain, the accuracy of temperature and strain are 0.15°C and 1.25 µStrain. [Othonos and
K Kalli, Fiber Bragg Gratings (Artech House, Boston, 1999)].
5
For the default gage length of 1 cm
6
Based on material properties of the standard sensor: polyimide-coated, low-bend-loss optical fiber. For temperatures up to 800°C,
contact Luna.
