1. Secure antenna to mast using the two supplied mast clamps. Clamps should be positioned
in the two channels on the antenna base as shown.
Note: Vent holes on the bottom of the antenna base must be kept clear, do not tape up
around bottom base of antenna.
Installation Instructions
Models: HG5812U-PRO
HG3511U-PRO
1.4" (35 mm) to 2" (50 mm) dia. mast
Antenna
Mast Clamps
Antenna Base
Clamp Channel
Clamp Channel
Vent Holes
