Configuring the Wireless Router
Connect to Unit with a cross-over cable to your PC or through a Switch (HUB) with
straight cables. Apply power to the Router unit. Check the diagnostic lights to ensure
proper connection. You should now be ready to configure the Router.
Launch the Network Configurator Utility
Click on File, Open Remote Config
Click on Scan to locate the Device
Select the Router to configure by Clicking on Name and Click on Change IP Button to
change to IP on your local subnet (similar to the configuration PC).
