Antenna Model
Gain (dBi)
29.6
29
28
27
26
20
16
15.5
HG2401U
1
9.6
8.9
8.0
7.1
6.3
3.2
2.0
2.1
HG2402RD
2
10.7
10.0
8.9
8.0
7.1
3.6
2.2
2.4
HG2403RD
3
12.0
11.2
10.0
8.9
8.0
4.0
2.5
2.4
HG2403UR
3
12.0
11.2
10.0
8.9
8.0
4.0
2.5
2.4
HG2404CU
3
12.0
11.2
10.0
8.9
8.0
4.0
2.5
3.0
HGV-2404U
4
13.5
12.6
11.2
10.0
8.9
4.5
2.8
3.0
HG2405RD
5
15.1
14.1
12.6
11.2
10.0
5.0
3.2
3.0
RE05E
5
15.1
14.1
12.6
11.2
10.0
5.0
3.2
3.0
RE05U
5
15.1
14.1
12.6
11.2
10.0
5.0
3.2
3.0
HG2405
5
15.1
14.1
12.6
11.2
10.0
5.0
3.2
-
HGV-2406U
6
17.0
15.9
14.1
12.6
11.2
5.6
3.6
HG2406U
6
17.0
15.9
14.1
12.6
11.2
5.6
3.6
-
HG2407U
7
N/A
17.8
15.9
14.1
12.6
6.3
4.0
-
HG2408U
8
N/A
20.0
17.8
15.9
14.1
7.1
4.5
-
HG2409U
8.5
N/A
N/A
18.9
16.8
15.0
7.5
4.7
-
HGV-2409U
8.5
N/A
N/A
18.9
16.8
15.0
7.5
4.7
-
HG2410U
10
N/A
N/A
22.4
20.0
17.8
8.9
5.6
-
HG2412U
12
N/A
N/A
N/A
25.1
22.4
11.2
7.1
-
HG2415U-PRO
15
N/A
N/A
N/A
N/A
31.7
15.9
10.0
-
Configurations with N/A are not permissible, via. FCC 15.247(b)(4)(i)
Configurations in RED can only be used in FIXED MOUNTED Installations
Configurations in BLACK Can be used in either MOBILE OR FIXED MOUNTED Installations
Appendix A: Minimum Separation Distance (cm)
