Ordering Guide
Create a model a model number in this format: L70100FR, IPC
Main Board L7 Extended Main Board, Green LEDs
L8 Extended Main Board, Red LEDs
Power 0 Isolated 85-264 Vac
1 Isolated 12-32 Vac or 10-48 Vdc
Relay Output
(isolated) 0 None
1 Two 8A Contact Relays
2 Two 120 mA Solid State Relays
3 Four 8A Contact Relays
4 Four 120 mA Solid State Relays
Analog Output
(isolated) 0 None
1 Single isolated 4-20 mA, 0-20 mA, 0-10V, -10 to +10V
2 Dual isolated 4-20 mA, 0-20 mA, 0-10V
Digital Interface
(isolated) 0 None
1 RS232
2 RS485 (dual RJ11 connectors)
4 RS485 Modbus (dual RJ45 connectors)
5 USB
6 USB-to-RS485 converter
7 Ethernet
8 Ethernet-to-RS485 converter
Pulse Rate or Totalizing
FR Dual-Channel Pulse Input Signal Conditioner Input Type
Voltage-to-Frequency Converter
VF1 V-to-F Converter, 4-20 mA
VF2 V-to-F Converter, 0-1 mA
VF3 V-to-F Converter, 0-10 V
VF4 V-to-F Converter, Special Range
For special range, specify min input, min reading; max input, max reading.
Component changes by the factory may be required.
Add-on Options BL Blank lens without button pads
CBL01 RJ11-to-DB9 cable
CBL02 USB-to-DB9 adapter
CBL05 USB Cable, A to B
IPC
Clear front panel cover sealed to NEMA 4X / IP65
BOX1 NEMA-4X wall-mount enclosure
BOX2 BOX1 plus IPC
