LAUREL

ELECTRONICS INC., 3183-G Airway Ave., Costa Mesa, CA 92626, USA • Tel 714-434-6131 • www.laurels.com 2

Specifications

Signal

Range
Input resistance
Bias current
Max input
NMR, 45 to 1000 Hz
CMR, 0 to 450 Hz

4-20 mA

22Ω

N/A

80 mA

56 dB
70 dB

0-10 V

1 MΩ

5 pA

100 V
56 dB
70 dB

Display

Format
Scale length

50 red LED segments
250 mm (9.84")

Accuracy

Resolution
Accuracy at 25÷C
Speed of response
Warm-up time
Calibration

1 part in 50
± 0.5% of full scale
100 msec
None required
Zero & span potentiometers

Power Supply

Voltage options
Power consumption

95 to 265 Vac or 11 to 30 Vdc
5W typ.

Environmental

Operating Temperature
Storage Temperature
Relative Humidity
Corrosion resistance
Protection

-20°C to 50°C (4°F to 122°F)
-40°C to 85°C (-40°F to 185°F)
0-90% RH at 40°C, non-condensing
Avoid chemicals harmful polycarbonate
NEMA-4 (IP65) all around

Case Dimensions

Bezel dimensions, wall mount
Bezel dimensions, panel mount
Panel mount cutout
Depth behind panel
Connectors

309 x 94 mm (12.17" x 3.70")
326 x 111 mm (12.83" x 4.37")
311 x 96 mm (12.24" x 3.78")
110 mm (4.33"), including connectors
Detachable screw-clamp connectors

Ordering Guide

Create a model a model number in this format: PB2000P

Display Type

PB Large Bargraph Display

Display Color

2 Red LEDs

Power

0 95 to 264 Vac
1 11 to 30 Vdc

Format

0 Vertical Format
1 Horizontal Format

Mounting

0 Panel Mount
1 Wall Mount

Signal Input

Process Signals ( 4-20 mA, 0-5 V, etc.)
P Default Scaling. 4-20 mA = 0-100%
P1 Custom Scaling

In the write-in field of your order, specify min input, min reading; max input, max
reading. 24 Vdc excitation.
