Ordering Guide
Create a model a model number in this format: L20000RMV1, IPC
DPM Type
L Laureate Digital Panel Meter
Main Board
1 Standard Main Board, Green LEDs
2 Standard Main Board, Red LEDs
Power
(isolated)
0 Isolated 85-264 Vac
1 Isolated 12-32 Vac or 10-48 Vdc
Relay Output
(isolated)
0 None
1 Two 8A Contact Relays
2 Two 120 mA Solid State Relays
3 Four 8A Contact Relays
4 Four120 mA Solid State Relays
Analog Output
(isolated)
0 None
1 Isolated 4-20 mA, 0-20 mA, 0-10 V, -10 to +10V
Digital Interface
(isolated)
0 None
1 RS232
2 RS485(dual RJ11 connectors)
4 RS485 Modbus (dual RJ45 connectors)
5 USB
6 USB-to-RS485 device server
7 Ethernet
8 Ethernet-to-RS485 device server
True AC RMS Volts
RMV1 200.00 mV
RMV2 2.0000 V
RMV3 20.000 V
RMV4 200.00 V
RMV5 600.0 V (range UL certified to 250V)
RMV6 250.0 V
Signal Input
(isolated)
True AC RMS Amps
RMA1 2.0000 mA
RMA2 20.000 mA
RMA3 200.00 mA
RMA4 5.000 A
Add-on Options
BL
Blank Lens without Button Pads
CBL01 RJ11-to-DB9 Cable
CBL02 USB-to-DB9 Adapter
CBL05 USB Cable, A to B
IPC
Splash-proof Cover
BOX1 NEMA-4 Enclosure
BOX2 NEMA-4 Enclosure plus IPC
