46
F.S.S. Parts Break Down
Replacement parts can be obtained from your reseller or the ADC factory. When ordering replacement parts
from the factory, FAX your order to ADC at (508) 678-9447 or telephone your order directly to the ADC Parts
Department at (508) 678-9000. Please specify the dryer model number and serial number in addition to the
description and part number, so that your order is processed accurately and promptly.
The illustrations on the following pages may not depict your particular dryer exactly. The illustrations are
composite of the various dryer models. Be sure to check the descriptions of the parts thoroughly before ordering.
We have tried to make this manual as complete as possible and hope it will be useful. ADC reserves the right to
make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and
to change or discontinue models.
Illus. No. Part No. Qty. Description
1 165114 1 F.S.S. System Solenoid Water Valve 24V 50/60 Hz
2 143220 1 3/8” F.P.T. Brass Tee
3 143251 1 3/8” M.P.T. Brass Plug
4 143208 2 3/8” Comp x 3/8” M.P.T. Brass Connector
5 143099* 6’ 3/8” OD x 0.035 Wall Copper Tubing
6 311588 1 Sprinkler Head Mounting Plate
7 143303 1 3/8” N.P.T. Brass Locknut
8 143155 1 3/8” Brass Elbow 90°
9 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
10 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
11 143581 1 3 GPM 3/8” F.P.T. Spray Nozzle
12 143025 1 3/4”-11.5 NH x 3/8” N.P.T. Hose Adapter
13 824081 1 R.C. Network Assembly
* Sold by the foot.
