Appendix C

LAN Boot Options

LittleBoard 550

Reference Manual

87

PXE Boot Agent Setup Screen

Use cursor keys to edit: Up/Down change field, Left/Right change value
Esc to quit; F9 restore previous settings, F10 to save

Argon Managed PC Boot Agent (MBA) v4.31 (BIOS integrated)
(C) Copyright 2002, Argon Technology Corporation
(C) Copyright 2003, 3COM Corporation
All rights reserved

Configuration

Boot Method: PXE

Default Boot:

Local

Local Boot:

Enabled

Config Message

Enabled

Message Timeout 3 seconds
Boot Failure Prompt:

Wait for timeout

Boot Failure:

Next boot device

Figure B-1. PXE Agent Boot Setup Screen

PXE Configuration

Boot Method: – [PXE], [TCP/IP], [NetWare], or [RPL]

Default Boot: – [Local] or [Network]

Local Boot: – [Disabled] or [Enabled]

Config Message: – [Disabled] or [Enabled]

Message Timeout: – [3 seconds], [6 seconds], [12 seconds], or [Forever]

Boot Failure Prompt: – [Wait for timeout] or [Wait for key]

Boot Failure: – [Next boot device] or [Reboot]

TCP/IP Configuration

Boot Method: – [PXE], [TCP/IP], [NetWare], or [RPL]

Protocol: – [DHCP] or [BOOTP]

Default Boot: – [Local] or [Network]

Local Boot: – [Disabled] or [Enabled]

Config Message: – [Disabled] or [Enabled]

Message Timeout: – [3 seconds], [6 seconds], [12 seconds], or [Forever]

Boot Failure Prompt: – [Wait for timeout] or [Wait for key]

Boot Failure: – [Next boot device] or [Reboot]
