RTC-700A
System
Processor NVIDIA® TEGRA™ 2 1.0GHz Dual Core Processor
System Memory DDR2 1GB SDRAM
LCD Display
7" WXGA (1280 x 800) TFT LCD with Projected Capacitive Multi-Touch screen,
Gorilla glass
Communication
WLAN 802.11 b/g/n
Bluetooth® 2.1
+ EDR (Bluetooth® Keyboard/Mouse support )
3G modem module (optional)
I/O Port
DC-in Jack x 1
Mini USB Port x 1
Mini HDMI Port x 1
Micro SD Card Slot x 1
3.5-mm stereo headphone jack x 1
Built-in Speaker & Microphone
SIM Card Slot x 1
Storage 16GB eMMC Flash
Navigation
GPS
E-compass
Camera
Front: 1.2M Pixel camera
Rear: 5M Pixel AF camera
Other
Built-in Light Sensor
Built-in G-Sensor, Built-in 3-axis digital gyroscope, Built-in Vibrator motor
OS Android™ v3.2/ v4.0
Mechanical
Color Black
Dimension 5.38” x 8.58” x 0.83”(136.6mm x 218mm x 21mm)
Gross Weight 1.2 lb (0.57 kg)
Carton Dimension 9.61” x 6.81” x 2.64” (244mm x 173mm x 67mm)
Environmental
Operating Temperature -4°F ~ 140°F (-20°C ~ 60°C)
Storage Temperature -67°F ~ 167°F (-55°C ~ 75°C)
Operating Humidity 10 to 95% @ 40°C, non-condensing
Water & Dust Proof IP65 compliance
Vibration
Meets MIL-STD-810G-514.6, Procedure I Cat. 24, Fig. 514.6E-1 & 514.6E-2
(Unit is non-operating)
ASTM 4169-99 Truck Assurance Level II, Schedule E (Unit is operating)
Drop
26 drops of 48 inches height to 2” plywood over concrete with unit off
MIL-STD-810G-516.6, Procedure IV
ESD Air +/- 8KV, Contact +/- 4KV
EMC/ Safety CE/ FCC Class B/ UL
NVIDIA® TEGRA™ 2 1.0 GHz Dual Core Processor ■ ■
DDR2 1GB SDRAM ■ ■
7” WXGA (1280 x 800) TFT LCD Display ■ ■
Projected Capacitive Multi-Touch Panel, Gorilla Glass ■ ■
Li-Polymer High-Capacity Battery, 6 Hours Battery Life ■ ■
Rugged, Water and Dust Proof, IP65 compliance ■ ■
Micro SD Card Slot, 5M Pixel Camera ■ ■
WiFI 802.11 b/g/n , Bluetooth® 2.1 ■ ■ + EDR, Optional 3G
G-Sensor, Light Sensor, E-compass, GPS Navigation ■ ■
Android™ v3.2/ V4.0 ■ ■
Sunlight Readable (Optional) ■ ■
RISC-based 7” Rugged Tablet Computer
Features
Specifications
