Support Port-Trunking with flexible load distribution control and fail-over functions
Provide 7 trunk groups of up to 4 member ports within 26 ports
Support ingress port security mode
Support by-port Egress/Ingress rate control
Support RMON group 1,2,3,9
Support Web/SNMP managed function with friendly user interface
LED display for each port status: link, activity and speed
LED display for fan status: normal or fail
SPECIFICATIONS
Standards compliance
IEEE 802.3 10BaseT Ethernet
IEEE 802.3u 100BaseTX Fast Ethernet
IEEE 802.3z 1000BaseSX/LX Gigabit
Ethernet
IEEE 802.3x flow control
IEEE 802.1D Spanning Tree
IEEE 802.1q Tag-based VLAN, Priority
Control
IEEE 802.1v port-based VLAN
IEEE 802.1x Authentication and
Authorization
Interfaces
24 100BaseTX RJ-45 STP ethernet ports
(switched ports)
2
1000BaseTX RJ-45 connector ports,
or 2 1000BaseSX/LX fiber ports
1 RS232
connector
Buffer Memory: 1M byte for control, 3M
byte for packet buffers
14/10/8/6K 64-bit, programmable size for
MAC entries
4/2K 128-bit, programmable size for VLAN
entries
1K 128-bit, IP multicast entries
Packet Forwarding and Filtering Rates:
1000M ethernet : 1488100 packets per second
per port
100M ethernet : 148810 packets per second
per port
10Methernet : 14880 packets per second per
port
Environment
Operation temperature: 5 to 45 centigrade
Operating humidity: 10%-90%, non-
condensing
Storage temperature: -20 to 70 centigrade
LED Panel Display
1 power LED: Green (normal),
1 self-diagnostic LED: Blinking during
power-on-diagnostics
Port LEDs: 1~ 24 ports, left corner of each
RJ-45 port, Green (Link ok), Blinking
(Activity)
Speed LEDs: 1 ~ 24 ports, right corner of
each RJ-45 port, Green ( 100M ), Vanish
( 10M )
FAN LEDs: FAN1 Red ( left side fan fail),
FAN2 Red ( right side fan fail )
Gigaport module LEDs: Orange( 10M Link
ok ), Green ( 100M link ok),
both Orange & Green
( 1000M link ok ), Blinking (Activity)
Power
Input: 100-240VAC, 50/60Hz,
Power Consumption: 35 Watts max.
Dimensions
440mm (W) X 184mm (D) X 44mm (H)
Weight :
2.3 kg
Electromagnetic Emissions
FCC, CE , VCCI, C-Tick
