GB - 9
CONTROLS AND FEATURES
Refer to Figure 1 on the inside front cover for controls
and features locations.
Ignition Switch
The ignition switch is operated with a removable key
that has two positions.
"STOP" Position: Ignition system is shut
down.
"RUN" Position: All controls are
operable.
To start the engine, the key must be in the "RUN"
position.
To stop the engine, turn the key to the "STOP" position.
Auger
When handlebar is lifted so auger contacts the ground,
auger propels unit forward while collecting snow.
Forward speed will vary according to depth and
moisture content.
Auger Clutch Bail
Squeeze the auger clutch bail
against the handlebar to engage
auger.
Release bail to disengage and
brake auger.
IMPORTANT: Check auger to be sure it is not frozen. If
belt squeals when clutch bail is engaged, auger is
frozen. Immediately release the clutch bail and move
the unit to a heated area to thaw.
IMPORTANT: Check clutch/brake function before each
use. If auger clutch bail moves freely with no resistance
before contacting handlebar, adjust or repair unit
before operating.
Primer Bulb
Push in the primer Bulb to add fuel for
easier engine start. See
Starting and
Shut Off .
Choke Control Knob
When pulled out (away from auger
housing) the choke control knob chokes
off air to the engine for easier start.
When pushed in, control knob allows for
normal operation.
IMPORTANT: When engine has started, open choke
slowly by gradually pushing choke control in.
Recoil Starter Handle
When pulled, handle will crank engine.
IMPORTANT: DO NOT let handle snap back against
unit.
Discharge Chute
The discharge chute directs the flow of snow away from
the area being cleared. The discharge chute rotates
220°. Rotate chute with the discharge chute handle.
WARNING: ACCIDENTAL ENGINE START
UP or UNAUTHORIZED USE could result in
death or serious injury. ALWAYS shut off unit
and remove key before servicing or leaving
unit unattended.
WARNING: THROWN OBJECTS could cause
personal injury and/or property damage.
ALWAYS discharge in a safe direction.
Disengage auger when unit is traveling to
work area or is not in use. Use extreme
caution when operating on or crossing gravel
surfaces.
CAUTION: STRIKING FOREIGN OBJECTS
may damage unit and result in minor or
moderate injury. Shut off unit and engine.
Check for any damage or loose parts and
repair before restart.
WARNING: IMPROPER ADJUSTMENT
could result in death or serious injury. AUGER
BRAKE MUST DISENGAGE when clutch is
engaged. BRAKE MUST STOP AUGER
WITHIN 5 SECONDS of releasing auger
clutch bail.
STOP
RUN
OS1680
DANGER: ROTATING PARTS will cause
serious injury or death. NEVER reach into
discharge chute or housing while engine is
running.
Engaged
Disengaged
OS1560
OS1620
OS1570
OPERATION
