7
Table 1: Front Panel Presentation Switcher / Scaler Features
# Feature Function
1 POWER Switch Illuminated switch for turning the machine ON or OFF
2 IR Receiver / LED Red when the unit accepts IR remote commands
3 AV1 Press to select the composite video/audio source 1
4 AV2 Press to select the composite video/audio source 2
5 YC1 Press to select the s-Video (Y/C)/audio source 1
6 YC2 Press to select the s-Video (Y/C)/audio source 2
7 COMPONENT Press to select the component video/audio source
8 DVI Press to select the DVI/audio source
9 VGA 2 1 Press to select the VGA/audio source 1
10
IN
P
U
T
S
E
LE
C
T
O
R
B
ut
to
ns
1
VGA 2 2 Press to select the VGA/audio source 2
11 PIP Button 3 Toggles the picture-in-picture function (see section 7.2)
12 BLANK Button Press to toggle between a blank screen (blue or black screen) 4 and the display
13 MUTE Button Press to toggle between muting (blocking out the sound) and enabling the audio
output
14 FREEZE Button Press to freeze/unfreeze the output video image 4
15 MENU Button Displays the OSD menu screen 5
16 ENTER Button Moves to the next level in the OSD screen
17 - Button Decreases the range by one step in the OSD screen 6
18 DOWN Button Moves down one step (in the same level) in the OSD screen 6
19 UP Button Moves up one step (in the same level) in the OSD screen 6
20 + Button Increases the range by one step in the OSD screen 6
21 RESET TO VGA Button Press and hold for a few seconds 7 to reset to the default output resolution
(640x480 @60Hz)
22 PANEL LOCK Button Press and hold to lock/unlock the front panel to prevent unintentional operation
1 When selected, button illuminates. See section 7.1 for details of how to program the INPUT SELECTOR buttons
2 Only the CVG-724xl has two VGA INPUT SELECTOR buttons. The CVG-719xl and CVG-720xl have one VGA button
3 Not available on the CVG-719xl
4 Also available via each INPUT SELECTOR button, when programmed accordingly (see section 7.1)
5 Or moves to the previous level in the OSD screen
6 When pressing the button continuously, you can speed up its response. For step-by-step response, press and release the
button as many times as needed
7 Until you see the screen refresh
