CVBS or S-Video + R/L to HDMI converter
1
Dear Customer
Thank you for purchasing this product. For optimum performance and safety, please
read these instructions carefully before connecting, operating or adjusting this
product. Please keep this manual for future reference.
1.0 INTRODUCTION
This CVBS or S-Video + R/L to HDMI converter is designed to make your A/V
equipment more comfortable, more productive and less expensive. It is a unique
device that converts an analog CVBS, S-VIDEO and AUDIO (L/R) signal to an HDMI
signal. This product not only meets the ideal image of the HDTV but also meets the
need of the enthusiasts’ requirement for audio. It improves the interlaced video signal
into 720P progressive signal.
This CVBS or S-Video + R/L to HDMI Converter offers solutions for noise, space and
security concerns, data center control, information-distribution, conference-room
presentation, school and corporate training environments.
1.1 FEATURES
Video signal can be up to HDTV 720p.
Automatically check (AUDIO delay)
Ensure the synchronization of AUDIO and VIDEO.
HDMI output: 720p@50Hz 720p@60Hz
Combine HDMI with AUDIO
Video output system: NTSC 3.58 / PAL(automatic)
compliant DVI by using HDMI-DVI adapter
2.0 SPECIFICATIONS
Signal Inputs/Output
Input Video Signal 1.2 volts p-p
Input DDC Signal 5 volts p-p (TTL)
Output Video HDMI
Video format supported
DTV/HDTV HDMI 720p@60Hz
Connector
HDMI Connector type A (19 pin) female
S-VIDEO Connector
AV Connector
Operating Frequency
Vertical Frequency Range 50/60Hz
Video Amplifier Bandwidth 1.65Gbps/165MHz
Mechanical
Size(L-W-H) 155x70x23MM
Weight for shipping 255G
Warranty 2 YEARS
