CNB G2960PF User Manual

Menu, Td rd gnd, Tx + tx - rx + rx

Digital Color Camera Series

P/N : 3810-0093A

(Ver.0612E)

Color Video Camera Series

Design and specifications are subject to
change without notice.

COLOR VIDEO CAMERA

Color CCD

COLOR VIDEO CAMERA

Color CCD

OWNER'S MANUAL

DIGITAL CAMERA SERIES

COLOR VIDEO CAMERA

Super Signal Noise Reduction

SSNR

On-Screen Display

OSD

DSP

•

D(O

n S

cre

Dis

pla

•

r D

ita

l N

•

DC 12V

Class 2 Only

MENU

POWER

VIDEO

VIDEO OUT

CONTROL

INFORMATION
This equipment has been tested and found to comply with limits for a Class A digital device, pursuant to part 15
of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at their own expense.

WARNING

The manufacturer could void the user's authority to operate the equipment.

CAUTION - To prevent electric shock and risk of fire hazards:

Do NOT use power sources except for that specified.
Do NOT expose this appliance to rain or moisture.

This installation should be made by a qualified service person and should abide to all local codes.

CAUTION! TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

Explanation of two Symbols

The lightning flash with arrowhead symbol, within an equilateral

triangle, is intended to alert the user to the presence of un-insulated

"dangerous voltage" within the product's enclosure that may be of

sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to

alert the user to the presence of important operating and maintenance-

(servicing) instructions in the literature accompanying the appliance.

THE GRAPHIC SYMBOLS WITH SUPPLEMENTAL MARKING ARE ON THE BOTTOM OF THE SYSTEM.

"WARNING-TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THE UNIT TO RAIN OR MOISTURE"

. User Information

1. SAFETY INSTRUCTIONS

2. PRECAUTIONS

3. FEATURES

4. NAME AND FUNCTIONS

5. OPERATING CAMERA

6. INSTALLATION (LENS)

7. COMPOSITION

8. CONNECTIONS

9. SPECIFICATIONS

.............

............................

..................................

.............

.................
.................

..........................

..................

...........................

..........................

...........................
...........................

.......................

.....................

...........

Before using this camera, please read this operation manual carefully to obtain
the best result and keep this manual for future reference.

Thank you for purchasing this COLOR VIDEO CAMERA.

. Lens Connector

. Control Jack

. Back-focus Adjustment

. Mounting a Lens

. AC 24V / DC 12V Input Model

. DC 12V Input Model

. Contents

Handling

Do not disassemble the camera and never touch
parts inside the camera.

Be sure the ambient temperature is less than
40℃ in installation intended for long term
continuous operation.

Avoid installing in a humid or dusty place.

Avoid installing in places where there are
strong magnetic fields and electric signals.

Avoid installing in places where the camera
would be subject to strong vibrations.

Never expose the camera to rain and water.

Installation and storage

Do not point the camera at the sun. This could
damage the camera whether it is operating or not.

Do not install the camera where the temperature
could exceed the allowable range.

Do not drop the camera or subject it to shocks
and vibrations to avoid possible damage.

When attaching or removing the lens, handle
with care in order to that moisture and dust do
not enter the camera.

2. PRECAUTIONS

Read Instructions
Read all of the safety and operating instructions
before using the product.

Installation
Do not place this product on an unstable cart, stand,
or table. The product may fall causing serious injury
to a child or adult, and damage to the product.
Use only with a cart or stand recommended by the
manufacturer, or sold with the product.
Mounting should follow the manufacturer's instructions,
and should use a mounting accessory recommended
by manufacturer.

Power source
This product should be operated only from the type
of power source indicated on the marking label.
If you are not sure of the type of power supplied to
your home, consult your dealer or local power
company.

Retain Instructions
Save this instructions for later use.

Cleaning
Unplug this appliance from wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.

Water and Moisture.
Do not use this product near water or moisture.
(For example. near a bathtub, wash bowl, kitchen
sink, or laundry tub, in a wet basement, or near a
swimming pool,etc)

1. SAFETY INSTRUCTIONS

High sensitivity 1/3 Inch Sony Super HAD CCD Pick-Up

Min lllumination : 0.3 Lux (Color)

0.02 Lux (B/W, DSS Off)

0.0005 Lux (B/W, DSS On)

Day & Night mode selectable.

High performance menus for functions

SSNR (Super Signal Noise Reduction)

It has an assistant reducing image noise efficiently and It shows clear and

sharp image display even in the dark

• Privacy zone selectable.

• Motion detection selectable.

• Super BLC selectable.

• Sharpness enhanced adjustable.

• Flickerless On/Off

• SENS-UP (DSS, Electronic Sensitivity-Up)

3. FEATURES

5. OPERATING CAMERA

LENS
SHUTTER
WHITE BALANCE
BACKLIGHT
AGC (Auto Gain Control)
SSNR (Super Signal Noise Reduction)
SENS-UP
SPECIAL

EXIT

• MANUAL • DC/VIDEO
• ESC • MANUAL • FLK
• ATW • MANUAL • AWC
• OFF • LOW • MIDDLE • HIGH
• OFF • LOW • MIDDLE • HIGH
• OFF • LOW • MIDDLE • HIGH
• OFF • AUTO
• CAMERA ID • COLOR • DZOOM • SYNC
• MOTION DET • PRIVACY • MIRROR
• SHARPNESS • RESET • RETURN

SETUP MENU

............................

......................................................

. Lens Connector Plug

(E-4-191J-100)

. Lens Mount Cap

. C-mount Adapter

. Owner's Manual

Design and specifications are subject to change without notice.

This color video camera is designed to output video signals conforming
to the NTSC(PAL) standard. So that it cannot be used with video recorder
or color monitors which use color systems other than NTSC(PAL).

The lens mount cap and C-mount adapter are attached when supplied.

7. COMPOSITION

DC 12V

Class 2 Only

MENU

POWER

VIDEO

VIDEO OUT

CONTROL

Connect the video output of the camera to the video input of a monitor or other equipment.
When using a "loop through" connection of two or more monitors, set the 75Ω switch of only the final
monitor to on. Determine the type of cable according to the distance of the connected equipment.

DC 12V

Power Source

NOTE

Do not turn any component's power

on until all connections are completed.

To Power input terminal

To Video input connector

8. CONNECTIONS

NTSC PAL

2:1 Interlace Transfer 1/3 Inch Super HAD CCD

768 (H) x 494 (V) 752 (H) x 582 (V)

Composite: 1.0Vp-p, 75Ω, Unbalanced

Internal Sync

More than 50dB (AGC OFF)

530 TV Lines

0.3 Lux (AGC ON), 0.02Lux (B/W DSS Off), 0.0005Lux (B/W DSS On)

C/CS Mount

Auto / Manual / Flickerless

x128~1/60~1/120,000 Sec.[NTSC], x128~1/50~1/120,000 Sec.[PAL]

ATW (1,900˚K~10,500˚K) / AWC / MANUAL

OFF / LOW / MIDDLE / HIGH

Signal System
Image Sensor
Effective Pixels
Video Output
Sync. System
Luminance S/N Ratio
Horizontal Resolution
Sensitivity (F1.2)
Lens Mount
Electronic Shutter

White Balance
BLC, AGC

High Resolution

MODEL

9. SPECIFICATIONS

OFF / LOW / MIDDLE / HIGH

ON / AUTO / B/W / EXT

8 x (On / Off)

ON / OFF (4 Programmable Zone)

ON / OFF (Horizontal)

ON / OFF (Level Adjustable)

DC Iris / Video Iris / Manual Lens

DC 12V(10V~15V)

180mA / 2.2W (Max)

-10℃~+50℃ (Recommendation:-5℃~+40℃)

-20℃~+60℃

65(W)x59.6(H)x122.5(D)mm / 59(W)x58(H)x123.75(D)mm

Approx. 430g

SSNR (Super Signal Noise Reduction)
Color (D&N)
D-ZOOM
Motion Detection
Privacy
Mirror
Sharpness
Applicable Lens
Supply Voltage
Power Consumption
Operating Temperature
Storage Temperature
External Dimensions
Weight

DC 12V Input Model

NTSC PAL

2:1 Interlace Transfer 1/3 Inch Super HAD CCD

768 (H) x 494 (V) 752 (H) x 582 (V)

Composite: 1.0Vp-p, 75Ω, Unbalanced

Internal Sync / Line-Lock Sync

More than 50dB (AGC OFF)

530 TV Lines

0.3 Lux (AGC ON), 0.02Lux (B/W DSS Off), 0.0005Lux (B/W DSS On)

C/CS Mount

Auto / Manual / Flickerless

x128~1/60~1/120,000 Sec.[NTSC], x128~1/50~1/120,000 Sec.[PAL]

ATW (1,900˚K~10,500˚K) / AWC / MANUAL

OFF / LOW / MIDDLE / HIGH

Signal System
Image Sensor
Effective Pixels
Video Output
Sync. System
Luminance S/N Ratio
Horizontal Resolution
Sensitivity (F1.2)
Lens Mount
Electronic Shutter

White Balance
BLC, AGC

High Resolution

MODEL

9. SPECIFICATIONS

OFF / LOW / MIDDLE / HIGH

ON / AUTO / B/W / EXT

8 x (On / Off)

ON / OFF (4 Programmable Zone)

ON / OFF (Horizontal)

ON / OFF (Level Adjustable)

DC Iris / Video Iris / Manual Lens

AC 24V (20V~28V) or DC 12V (10V~15V)

330mA / 4W (Max)

-10℃~+50℃ (Recommendation:-5℃~+40℃)

-20℃~+60℃

65(W)x59.6(H)x122.5(D)mm / 59(W)x58(H)x123.75(D)mm

Approx. 430g

AC 24V / DC 12V Input Model

WITH A ZOOM LENS
1) Fully open the aperture and set the lens to the maximum tele-photo position. Then turn the focus ring to focus.
In the case of an auto-iris lens only, shoot a comparatively dark object so that the aperture is fully open.
2) Set the lens to its maximum wide-angle position.
3) Loosen the two back-focus screws with a L-wrench, and turn the lens mount to focus.
4) After adjusting the back-focus, tighten the back-focus screw.
5) Repeat step 1)~3) until the difference between focusing position 1) and 2)becomes smallest.

CAUTION : Do not forcibly turn back-focus screw, it could cause damage to the camera.

When a lens is mounted, adjustment of the back-focus may sometimes be required.
Adjust the lens focus ring when the correct focus cannot be obtained.

WITH A FIXED-FOCUS LENS
1) Fully open the aperture and set the focus ring to "∞"(infinity).
In the case of an auto-iris lens only, shoot a comparatively dark object so that the aperture is fully open.
2) Loosen the two back-focus screws with a L-wrench, and turn the lens mount to focus.
3) After adjusting the back-focus, tighten the back-focus screw.

Back-focus Adjustment

Remove the lens mount cap from the camera.

Attach or remove the C-mount adapter depending on the lens to be used.

Attach the lens to the lens mount. Secure it so that it does not become loose.

If the lens has an auto-iris mechanism, connect the lens cable to the lens connector.

- When installing a video-iris lens, lens switch should be set to VIDEO position.
- When installing a galvanometric-iris lens, lens switch should be set to DC position.

- If the adapter is attached so tightly that it is difficult to remove it.
(Keep the C-mount adapter for possible future use.)

Mounting a Lens

Video Type lens : Set lens Switch to Video. Connect the lens cable of a video Type lens.
If the plug on the cable is a different type, replace it with the provided 4-pin iris plug.

DC type lens : Set lens switch to DC. Connect the lens cable of a DC(Galvanometric) type lens.
If the plug on the cable is a different type, replace it with the provided 4-pin iris plug.

Pin Assignment :

Pin No.

#1
#2
#3
#4

Signal

+9V DC

N.C

Video(1.0Vp-p, high impedance, no sync)

GND

VIDEO Iris Type Lens

Pin No.

#1
#2
#3
#4

Signal
Damping coil (-)
Damping coil (+)
Drive coil (+)
Drive coil (-)

DC Iris Type Lens

When using an auto-iris lens, install the accessory lens plug
on the lens cable as follows.

NOTE

After installing the connector plug, connect it to

the lens connector on the rear panel of camera.

Lens Connector

- DOWN Button
- UP Button
- LEFT Button
- RIGHT Button
- MENU(SET) Button

Use five buttons on rear side of the camera.

SETUP
- Press the MENU button to access the setup mode.
• Select the status using the ◀, ▶, ▲, ▼ button.
• Move the cursor to character enter location by
using the button.

Setting up the Menu

SETUP

LENS
SHUTTER
WHITE BAL.
BACKLIGHT
AGC
SSNR
SENS-UP
SPECIAL
EXIT

MANUAL
ESC
ATW
OFF
LOW
LOW
OFF

1. Press the MENU button to access the SETUP mode.

• SETUP menu is displayed on the monitor screen.

2. Select the desired feature using the UP or DOWN button.

• Each time you press the UP or DOWN button, the arrow indicator moves UP or DOWN.

• Move the arrow indicator the desired feature item.
3. Change the status of the selected feature using the LEFT or RIGHT button.

• If you Press RIGHT or LEFT button, it appears available status. Press the button when gets desired feature.
4. When completed, move the arrow indicator to 'EXIT' and press the MENU button.

Main Menu -

SETUP

LENS

SHUTTER

WHITE BAL.

BACKLIGHT

AGC

SSNR

SENS-UP

SPECIAL

EXIT

---

AWC

HIGH

LOW

AUTO

You can access submenu using MENU button.
For the mode with '---', you may not access submenu.

NOTE

Main Menu -

LENS

1) Setting up the LENS

Select the lens pressing the RIGHT button.

SETUP

LENS

SHUTTER

WHITE BAL.

BACKLIGHT

AGC

SSNR

SENS-UP

SPECIAL

EXIT

MANUAL

FLK

AWC

HIGH

OFF

---

SETUP

LENS

SHUTTER

WHITE BAL.

BACKLIGHT

AGC

SSNR

SENS-UP

SPECIAL

EXIT

---

AWC

HIGH

LOW

AUTO

① On the SETUP menu screen, move the arrow indicator to the lens using the UP or DOWN button.

② Select the desired feature using the LEFT or RIGHT button.

Main Menu -

WHITE BALANCE

3) WHITE BAL. (White Balance)

When you need to control the color on the screen, use 'WHITE BALANCE' function.

SETUP

LENS

SHUTTER

WHITE BAL.

BACKLIGHT

AGC

SSNR

SENS-UP

SPECIAL

EXIT

---

AWC

HIGH

OFF

---

① Press the MENU button to display the SETUP menu and move the arrow indicator to 'WHITE BAL.'

using the UP or DOWN button.
② Set 'WHITE BAL.' To the desired mode using LEFT or RIGHT button.

ATW(Auto Tracking White Balance): When color temperature is 1,900˚K~10,500˚K, select this mode.

(ex. A fluorecent lamp, outdoor)

AWC(Auto White Balance Control): The white balance is automatically adjusted in a specific environment.

In order to obtain the best result, press the set button while the camera focuses on white paper.

If the environment including the light source is changed, you have to adjust the white balance again.

2) Shutter status and speed control

You can control brightness of the screen by the shutter speed.

SETUP

LENS

SHUTTER

WHITE BAL.

BACKLIGHT

AGC

SSNR

SENS-UP

SPECIAL

EXIT

---

AWC

HIGH

OFF

---

SETUP

LENS

SHUTTER

WHITE BAL.

BACKLIGHT

AGC

SSNR

SENS-UP

SPECIAL

EXIT

MANUAL

FLK

AWC

HIGH

OFF

---

① Press the MENU button to display the setup menu and move the arrow indicator to 'SHUTTER' using the UP or DOWN button.

② Set 'SHUTTER' to the desired mode using the LEFT or RIGHT button.

--- : Deactivation

FLK: Flickerless mode
- NTSC (1/100)
- PAL (1/120)

Main Menu -

SHUTTER SPEED CONTROL(1)

AUTO IRIS LENS(DC TYPE)is recommended than MANUAL LENS.
Some lens can make a malfunction according to the BRIGHTNESS LEVEL.

NOTE

When DC LENS selected, press MENU button to control the BRIGHTNESS.

Brightness

Press SET to Return

BRIGHTNESS

Main Menu -

SHUTTER SPEED CONTROL(2)

SETUP

LENS

SHUTTER

WHITE BAL.

BACKLIGHT

AGC

SSNR

SENS-UP

SPECIAL

EXIT

MANUAL

AWC

HIGH

OFF

---

MANUAL : When setting shutter speed manually.(Only for manual LENS mode)

You can select speed from

- NTSC (x128~x2, 1/60~1/120,000 sec.)
- PAL (x128~x2, 1/50~1/120,000 sec)

SHUT TER

Press SET to Return

MANUAL

1/60

Main Menu -

SSNR

6) SSNR (Super Signal Noise Reduction)

SSNR reduces the noise on the screen.

SETUP

LENS

SHUTTER

WHITE BAL.

BACKLIGHT

AGC

SSNR

SENS-UP

SPECIAL

EXIT

---

AWC

HIGH

OFF

---

① Press the MENU button to display the SETUP menu and move the arrow indicator to 'SSNR' using the UP or

DOWN button.
② SET 'SSNR' to the desired mode using the LEFT or RIGHT button.

OFF : Deactivation
LOW : Low reduction

of the noise
MIDDLE : Middle

reduction of the noise
HIGH : High reduction

of the noise

Afterimage may appear with SSNR activated.

When selected 'AGC' menu OFF, SSNR doesn't work.(---)

If you change the 'AGC' menu from AGC-L to AGC-H, sensitivity is

increasing as well as noise on the screen.

NOTE

MANUAL : To fine adjust, select the Manual mode. You can increase or decrease the red

or blue factor while monitoring the difference on the screen. Set to 'MANUAL'

mode and press the MENU button, lncrease or decrease the value for RED(R-Gain)

and BLUE(B-Gain), watching the color of the picture, and press the MENU button

when you obtain the best color.

Proper White Balance may not be obtained under the following

conditions, in these cases select the AWC mode.

- When the scene contains mostly high color temperature object,

such as a blue sky or sunset.

- When the scene is dim.

- If your camera faces fluorescent lamp directly or is installed in the

place of the changing illumination.

NOTE

③ When completed, press 'MENU'

SETUP

LENS

SHUTTER

WHITE BAL.

BACKLIGHT

AGC

SSNR

SENS-UP

SPECIAL

EXIT

MANUAL

ESC

AWC

HIGH

OFF

---

ESC : You can control

the BRIGHTNESS.

Don't expose the camera to fluorescent lamp directly not to get unstable

image in the internal synchronization modes.
When the SHUTTER menu is set to FLK mode. SENS-UP dose not operate.

NOTE

Brightness

Press SET to Return

BRIGHTNESS

Main Menu -

AGC

5) AGC (Auto Gain Control)

AGC is to get bright picture. Higher GAIN level, getting brighter screen. But you can get noise increase.

SETUP

LENS

SHUTTER

WHITE BAL.

BACKLIGHT

AGC

SSNR

SENS-UP

SPECIAL

EXIT

---

AWC

HIGH

OFF

---

① Press the MENU button to display the SETUP menu and move the arrow indicator to 'AGC' using the

UP or DOWN button.
② SET 'AGC' to the desired mode using the LEFT or RIGHT button.

OFF

LOW

MIDDLE

HIGH

8) SPECIAL

SETUP

LENS

SHUTTER

WHITE BAL.

BACKLIGHT

AGC

SSNR

SENS-UP

SPECIAL

EXIT

---

AWC

HIGH

OFF

---

SPECIAL

CAMERA ID

COLOR

DZOOM

SYNC

MOTION DET

PRIVACY

MIRROR

SHARPNESS

RESET

RETURN

---

OFF

INT

OFF

① Press the MENU button to display the SETUP menu and move the arrow indicator 'SPECIAL' using the UP or DOWN button.

② SET 'SPECIAL' to the desired mode using the LEFT or RIGHT button.

① Press the MENU button to display the SETUP menu and move the arrow indicator to 'CAMERA ID' using the UP or DOWN button.

② SET 'ON' using the LEFT or RIGHT button.

③ Press the MENU button to

access the SETUP mode.

Menu [SPECIAL]-

CAMERA ID (1)

CAMERA ID

① Press the MENU button.

: Configure Zoom magnification rate from x1 ~ x8 using this feature.

② Please select the ZOOM RATE from x1 ~x8.

Menu [SPECIAL]-

DZOOM

SPECIAL

CAMERA ID

COLOR

DZOOM

SYNC

MOTION DET

PRIVACY

MIRROR

SHARPNESS

RESET

RETURN

---

OFF

INT

OFF

① Press the MENU button to display the setup menu and move the arrow indicator to 'COLOR' using the

UP and DOWN button.

: You can choose color and B/W mode electronically.(OPTION)

② SET 'COLOR' to the desired mode using the LEFT or RIGHT button.

--- : Deactivation

ON : Color mode

AUTO : According to the

input luminance level, IR

Cut Filter is automatically

switched to the appropriate

mode for daytime or night-

time. The COLOR mode is

operated for daytime, and

it converts to BW mode

for night-time.

B/W : BW mode. Please SETUP button to turn on or off the burst signal on BW mode.

EXT : It enables user to control DAY or NIGHT mode by external input signal. (Refer to P44)

COLOR

Menu [SPECIAL]-

SYNC

SPECIAL

CAMERA ID

COLOR

DZOOM

SYNC

MOTION DET

PRIVACY

MIRROR

SHARPNESS

RESET

RETURN

OFF

---

INT

OFF

① Press the MENU button to display the setup menu and move the arrow indicator to 'SYNC' using the

UP and DOWN button.

: Two Synchronization modes are available Internal and External Line-Lock.

In Line-Lock mode, it synchronous the video signal between cameras without a synchronous generator.

The line-lock synchronization is only used in the area of 60Hz(NTSC Type)/ 50Hz(PAL Type)

② SET to the desired mode using the LEFT or RIGHT button.

INT : Internal

synchronization

L/L : If you choose

'L/L', you can adjust

the desired phase.

- Press the MENU button.
- You can adjust the

desired phase from

0 to 359.

When it used in AC power, L/L mode can be used.
In DC12V, the SYNC is fixed to 'INT' mode.

NOTE

SYNC

Menu [SPECIAL]-

PRIVACY

SPECIAL

CAMERA ID

COLOR

DZOOM

SYNC

MOTION DET

PRIVACY

MIRROR

SHARPNESS

RESET

RETURN

---

OFF

INT

OFF

① Press the MENU button to display the setup menu and move the arrow indicator to 'PRIVACY' using the

UP and DOWN button.

: To conceal the areas you do not wish to appear on the screen.

② SET 'PRIVACY' to the desired mode using the LEFT or RIGHT button.

OFF : Deactivation

ON : PRIVACY mode

activated

- Press the MENU button and

then set the area's bounds

with the method like MOTION DET. Set

- Set 'ON' using LEFT or

RIGHT button.

- Move the arrow indicator

to area you want to mask.

- Press the MENU button.

PRIVACY

: This mode reverses the image horizontally.

Menu [SPECIAL]-

MIRROR

SPECIAL

CAMERA ID

COLOR

DZOOM

SYNC

MOTION DET

PRIVACY

MIRROR

SHARPNESS

RESET

RETURN

---

OFF

INT

OFF

① Press the MENU button to display the setup menu and move the arrow indicator to 'MIRROR' using the

UP and DOWN button.

② SET 'MIRROR' to desired mode using the LEFT or RIGHT button.

OFF : Deactivation

ON : Reverse image

LEFT and RIGHT.

MIRROR

Menu [SPECIAL]-

MOTION DETECTION

SPECIAL

CAMERA ID

COLOR

DZOOM

SYNC

MOTION DET

PRIVACY

MIRROR

SHARPNESS

RESET

RETURN

---

OFF

INT

OFF

① Press the MENU button to display the setup menu and move the arrow indicator to 'MOTION DET' using the UP and DOWN button.

: The camera detects an object's movement by sensing disparity of outline,

and level of brightness and color.

② SET 'MOTION DET' to the desired mode using the LEFT or RIGHT button.

OFF : Deactivation the

motion detection mode.

ON : Any motion in the

selected area is observed.

- Please select the area you

wish to observer from the

4 different areas.

- Move the arrow indicator

to 'AREA SET' using UP

and DOWN button, and

then press the MENU button.

- Press MENU button.

MOTION DET

MOTION DETECTION

Press SET to Return

AREA SEL

AREA STATE

TOP

DOWN

LEFT

RIGHT

AREA1

Menu [SPECIAL]-

SHARPNESS

① Press the MENU button to display the setup menu and move the arrow indicator to 'SHARPNESS' using

the UP and DOWN button.
② SET 'SHARPNESS' to the

desired mode using the

LEFT or RIGHT button.

SPECIAL

CAMERA ID

COLOR

DZOOM

SYNC

MOTION DET

PRIVACY

MIRROR

SHARPNESS

RESET

RETURN

---

OFF

INT

OFF

OFF : Deactivation.

SHARPNESS

Press SET to Return

LEVEL

ON : SHARPNESS

control mode(level 0~31)

when the level is up, the

sharpness will make

image clear.

Please control the level

as you want to get.

Menu [SPECIAL]-

RESET / RETURN

RESET

: Save the setting of SPECIAL function, and then move to SETUP menu.

RETURN

: To reset your camera to the factory default setting.

: The outline of the video image becomes cleaner and more distinctive as the level of SHARPNESS increases.

PRIVACY

Press SET to Return

AREA SEL

AREA STATE

AREA TONE

TOP

DOWN

LEFT

RIGHT

AREA1

SPECIAL

CAMERA ID

COLOR

DZOOM

SYNC

MOTION DET

PRIVACY

MIRROR

SHARPNESS

RESET

RETURN

---

OFF

INT

OFF

③ Please adjust the size of the area to be observed by using the UP, DOWN, LEFT or RIGHT button.

Max

Min

MOTION DETECTION

Press SET to Return

AREA SEL

AREA STATE

TOP

DOWN

LEFT

RIGHT

AREA1

Main Menu -

BACKLIGHT

4) BACKLIGHT (Back Light Compensation)

When there is a strong backlight behind the object, clear images of the background as well as the object can

still be obtained by using the BACKLIGHT function.

SETUP

LENS

SHUTTER

WHITE BAL.

BACKLIGHT

AGC

SSNR

SENS-UP

SPECIAL

EXIT

---

AWC

HIGH

OFF

---

① Press the MENU button to display the SETUP menu and move the arrow indicator to 'BACKLIGHT' using the UP or DOWN button.

② SET 'BACKLIGHT' to the desired mode using the LEFT or RIGHT button.

OFF

LOW

MIDDLE

HIGH

BLC ON

BLC OFF

1) CAM TITLE (Camera Title)

If the CAMERA ID feature is set to 'OFF', the name will not displayed in the monitor.

② Press the MENU button to access the SETUP mode.

① SET 'ON' using the LEFT or RIGHT button.

③ You can enter up to 15 characters.

• Move the cursor to character-enter location by using the LEFT or RIGHT button.

• Select the desired character by using the UP or DOWN button.

• Press the MENU button to confirm the blinking character. The first character is saved and the cursor

in the bottom of the screen moves to the next position.

• Repeat steps a, b and c until you create the full name you want.

• Select the position at which the CAMERA ID will be located on the screen.

- Move the cursor to 'POS' and press the MENU button.

- Select the position by using the 4-directional buttons, then press the MENU button to confirm the position.

• When completed, move the cursor to 'END' and press the MENU button.

Menu [SPECIAL]-

CAMERA ID (2)

CAMERA ID

Press SET to Return

CAM TITLE

CAM ID No.

EXIT

DZOOM

Press SET to Return

RATE

ZOOM RATE X1.0

Menu [SPECIAL]-

COLOR

If the level goes up excessively, you can get the unnatural image with noise.

NOTE

2) CAM ID No. (Camera ID No.)

② Camera ID can be specified using numbers from 0 to 255 by using the LEFT or RIGHT button.

① Display the camera's ID.

If you make a mistake while entering name Move the cursor to 'CLR', press 'SET'

button. After erasing the character from right to left. Correct the character again.

NOTE

CAMERA ID

ABCDEFGHIJKLM

NOPQRSTUVWXYZ

a b c d e f g h i j k l m

nopqrstuvwxyz

-. 0123456789
← →

CLR POS END

_______________

4. NAME AND FUNCTIONS

Holder Screw Hole

Used to install the camera on an optional

holder.(Tripod or Bracket)

The optional holder must be equipped with

the screw specified as shown right.

CS-Mount Holding Screw

Used to readjust back focus of the camera.

There are two back focus lock screws.

These must be loosened before the camera

may be back focused.

Loosen the lock screws to turn the CS-mount

lens adaptor, and tighten the lock

screws after adjustment.

Auto Iris Lens Connector

Used to connect Auto Iris Lens plug.

C-Mount Lens Adapter

Used to attach C-mount lens.
CS-Mount Lens Adapter

Used to attach CS-mount lens.

1/4"- 20 UNC (20 THREAD)

L : 4.5mm±0.2mm (ISO standard),

or 0.197" (ASA standard)

② Lens Selection Switch

Used to choose DC or VIDEO or ELC according to the type of your Lens.

④ POWER Input Terminal

Used to connect an AC 24V or DC 12V power source.

Used to connect a DC 12V power source.
⑤ VIDEO OUT Jack

Used to connect an external video monitor in jack.

③ Remote Jack (See page 43)

Used to connect remote plug.

① Function Setup Button

Functions can be setup using 5 buttons on the camera's rear panel.

MENU Buttons : Used to access menu mode.

Also used to escape menu mode.
UP / DOWN Buttons : Used to choose the desired

menu item. It also moves the cursor up or down in

the menu screen.
LEFT/RIGHT Buttons: Used to change the parameter

of the selected menu item. It also moves the cursor

the left of right in the menu screen.

MENU

Please insert a lens cable when using the DC iris lens or
Video iris lens.

Lens select switch on the rear pannel should be set to
DC or VIDEO position when using
the AUTO iris lens.

When using the VIDEO type lens, please adjust a brightness
of image with volume attached with the lens.

When using the DC type lens, please
adjust a brightness of image by setup
menu on the rear panel.

6. INSTALLATION

(LENS)

Control Jack

VIDEO

VIDEO OUT

CONTROL

1 2 3 4 5

GND

NAME

1. Frame GND

2. RD

3. TD

4. DTR

5. Signal GND

6. DSR

7. RTS

8. CTS

9. RI

PC Interface

Tx +

Tx -

Rx +

Rx -

3
4
5

8
9

R +

R -

T +

T -

RS-232C D-Sub Connector (PC)

RS-232C TO RS-422 Converter

No.

Function

1
2
3
4
5

R+ (RS-485)
R- (RS-485)

MOTION DET. OUTPUT "H"

GND

DAY/NIGHT INPUT(EXT) "L"

: It is a terminal that controls the function of the camera at long distance.

Remote Input Jack (RS485)

: It is the function that can be switched to DAY Mode or NIGHT Mode by receiving the Day/Night

on/off signal from external light sensor or IR LED LAMP.

When Day / Night Mode is set " EXT" on the OSD menu of the Camera.

DAY / NIGHT External Input

Motion Det Output

3sec

There is no motion

+3V

There is motion

3
4

GND

Motion Det Out

Open contact : DAY
Close contact : NIGHT

4
5

D/N ON (EXT)

GND

MD(Motion Detection) Output Signal Level(less than 10mA)

DC 12V

① Function

Setup Button

⑤ Video Out Jack

③ Remote Jack

② Lens Selection

Swicth

④ Power Input

Terminal

Class 2 Only

MENU

POWER

VIDEO

VIDEO OUT

CONTROL

DC 12V Input Model

MENU

POWER

VIDEO

VIDEO OUT

CONTROL

AC 24V / DC 12V Input Model

Class 2 Only

AC 24V / DC 12V

7) SENS-UP (Sensitivity-Up)

SENS-UP makes camera's sensitivity up so you can get a bright, clear screen image by automatically detecting

changes in the level of light in low light level conditions.

SETUP

LENS

SHUTTER

WHITE BAL.

BACKLIGHT

AGC

SSNR

SENS-UP

SPECIAL

EXIT

---

AWC

HIGH

OFF

---

① Press the MENU button to display the SETUP menu and move the arrow indicator to 'SENS-UP' using the

UP or DOWN button.
② SET 'SENS-UP' to the desired mode using the LEFT or RIGHT button.

AUTO : When your

camera is under night

or low-lighting level.

Select this mode.

OFF : Deactivation

If you press MENU button at 'AUTO' menu, you can control the lowlight

action maximum magnifications. (x2~x128)

When increasing the magnifications in case of SENS-UP activated.

It may appear noise, spots, whitish, This is not out of order.

Expander the magnifications, you can get the brighter screen as well as the afterimage.

NOTE

Main Menu -

SENSE-UP

When the SHUTTER menu is set to FLK mode. SENS-UP dose not operate.

. Memo

This manual is related to the following products:

G2960NF
