OWNER'S MANUAL

Before operating the camera, confirm that you have the right
camera model and proper power voltage.
In order to help you understand this manual, we'll introduce
our model's description.

Thank you for purchasing this COLOR VIDEO CAMERA.

If you have trouble operating your camera, refer to the following table.
If the guidelines do not enable you to solve the problem, contact an
authorized technician.

Problem

Solutions

Nothing appears on
the screen.

The image on the
screen is dim.

The image on the
screen is dark.

The camera is not
working properly,
and the surface of
the camera is hot.

The image on the
screen flickers.

• Check that the power cord and line connection
between the camera and monitor are fixed properly.
• Check that you have properly connected VIDEO
cable to the camera VIDEO output jack.

• Is lens stained with dirt? Clean your lens with soft,
clean cloth.
• Set the monitor to proper condition.
• If the camera is exposed to too strong light, change
the camera position.
• Adjust the lens focus properly.

• Adjust the contrast feature of the monitor.
• If you have an intermediate device, set the 75Ω/ Hi-z
properly. (refer to page 10)

• Check that you have properly connected the camera
to an appropriate power source.
(refer to page 11)

• Is the camera facing to direct sunlight or fluoresent
lighting? Change the camera position.

Precautions

Composition

Features

Name and Function of Each Parts

Installation

Remote Controller Operation

On-Screen Display

Menu Format

Menu Format Table

Communication Protocol

Troubleshooting

Specifications

1.

2.

3.

4.

5.

6.

7.

8.

9.

10.

11.

12.

5

6

7

8

10

14

16

18

19

20

21

22

CAUTION! TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

Explanation of two Symbols

The lightning flash with arrowhead symbol,

within an equilateral triangle, is intended to

alert the user to the presence of un-insulated

"dangerous voltage" within the product's

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and

maintenance-(servicing) instructions in the

THE GRAPHIC SYMBOLS WITH SUPPLEMENTAL MARKING ARE
ON THE BOTTOM OF THE SYSTEM.

"WARNING-TO PREVENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THE UNIT TO RAIN OR MOISTURE"

enclosure that may be of sufficient magnitude to constitute a

risk of electric shock to persons.

literature accompanying the appliance.

3

COLOR VIDEO CAMERA

2

Weatherproof Zoom

5

COLOR VIDEO CAMERA

4

Weatherproof Zoom

7

COLOR VIDEO CAMERA

6

Weatherproof Zoom

11

10

Weatherproof Zoom

13

COLOR VIDEO CAMERA

12

Weatherproof Zoom

15

COLOR VIDEO CAMERA

14

Weatherproof Zoom

19

COLOR VIDEO CAMERA

18

Weatherproof Zoom

21

COLOR VIDEO CAMERA

20

Weatherproof Zoom

23

COLOR VIDEO CAMERA

22

Weatherproof Zoom

9

COLOR VIDEO CAMERA

8

Weatherproof Zoom

17

COLOR VIDEO CAMERA

16

Weatherproof Zoom

COLOR ZOOM CAMERA SERIES

with DAY & NIGHT

INFORMATION

This equipment has been tested and found to comply with limits for a
Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct
the interference at their own expense.

WARNING

The manufacturer could void the user's authority to operate the
equipment.

CAUTION - To prevent electric shock and risk of fire hazards:

Do NOT use power sources except for that specified.

This installation should be made by a qualified service person
and should abide to all local codes.

P/N : 3810-0102B

(Ver.0703E)

Color Zoom Camera Series

Digital Zoom Camera Series

Design and specifications
are subject to
change without notice.

DSS

DSS

Weatherproof

Day & Night Color Camera

Weatherproof

Day & Night Color Camera

Digital Slow Shutter

• Electronic Iris

Electronic iris shutter is automatically controlled at the speed of

1/60 ~ 1/10,000sec (NTSC models),

1/50 ~ 1/10,000sec (PAL models).

• Remote Control through RS-485 (Pelco-D)

Remote control operations are possible though RS-485 interface for

focus and zoom control. In addition, the unit lets you command

white balance and exposure manually using RS-485 interface.

• Heater

Depends on internal temperature, it operates automatically.

- Heater ON : under 10°C

• High Sensitivity (Digital Slow Shutter)

Digital Slow Shutter is a function which enhances camera's sensitivity

electronically. When DAY/NIGHT mode is Auto, it automatically judges

whether it is day or night. Color images are provided in Day mode

and B/W images in Night mode. DSS setting value is fixed to 2 fields

of integration and twice the brightness in Night mode.

• High Resolution

The horizontal resolution of 480 TV lines can be achieved by

using a high density CCD having effective 410K(NTSC) pixels, which

provides clean, noiseless and reliable pictures.

• Built-in Power Zoom Lens

Subjects can be magnified up to 220 times with 22x optical zoom

and 10x digital zoom.

3. Features

Do use the camera under conditions where temperatures are within
-10°C to 45°C. Especially be careful for ventilation under high temperature.
(with heater : -30°C ~ 45°C)

Do not install the camera in extreme temperature conditions.

Do not install or use the camera in an environment where the

humidity is high.

It can cause the image quality to be poor.

Do not install the camera under unstable lighting conditions.
Severe lighting change or flicker can cause the camera to work improperly.

Never use the camera close to a gas or oil leak.

It can cause malfunctions to occur.

Do not disassemble the camera.

There are no user-serviceable parts inside it.

It can cause malfunctions to occur.

Do not drop the camera or subject them to physical shocks.

Never keep the camera face to strong light directly.

It can damage CCD.

Note
When this camera is installed near wireless communication
devices that emits strong electromagnetic field, irregularity
such as noise on the monitor may appear.

1. Precautions

2. Composition

. Dimensions(mm)

11. Troubleshooting

. Contents

. User Information

Sunvisor

Bracket Supporter

Wall Mount Bracket

Base Adapter

L-Wrench

L-Torx Wrench

Service Monitor Cable

Owner's Manual

BNC Cable

4. Name and Function of Each Parts

7. On-Screen Display

Fixing Bolt for Sunvisor:

You can unfasten the bolt in order to fix mounting bracket above.
Photo Sensor
Sunvisor:

To reduce direct sunlight and protect the camera unit from rain

or snow in outdoor.
Front Body

Base Adapter
Base Adapter Fixing Bolt
⑨ Wall Mount Bracket
Bracket Supporter

Rear Body
Mounting Bracket Fixing Bolt:

Fix the camera main body to

bracket by wrench bolt.

•Po

wer

ful

Zo

om

in

g F

unc

tio

n M

ax

. 2

20

x

Zo

om

(2

2x

O

pt

ic

al

/1

0x

D

igi

tal)

5. Installation

Cable the VIDEO out to the monitor video in jack.

Assembling the sunvisor and the bracket.

Assembling the bracket supporter

Weatherproof

IR LED Camera

Monitor

Intermediate

Video Receiver

End monitor

• As the connecting method varies with the instruments, refer to the
manual supplied with the instrument.

• Set the 75Ω/ Hi-Z selection switch as shown below if you have an
intermediate device.

• Connect the cable after power is turned off.

Weatherproof

IR LED Camera

Connecting to Monitor

The OSD (On Screen Display) is as follows:

Explanation of the On-Screen Display

Camera Installation

Camera Installation

#3

#4

Hex Scoket Bolt

(1EA)

Base Adapter

Fixing Bolt
(4EA)

Mounting Bracket

Fixing Bolt
(1EA)

Weatherproof

Zoom Camera

Connecting to Power Supply

- The wire is non-polarized.

- Use AC 24V power source or DC 12V power source.

. AC 24V / DC 12V Power

Black

Yellow

Service Connector (Extra Video Out Connector)
This camera system includes a service connector that outputs
extra camera video signal. Use it at the installation site to set up
the field of view and focus the camera.

MENU Button
Used to access OSD menu mode or escape menu from mode.

TELE/WIDE Buttons
Used to choose the desired menu item.
It also moves the cursor up or down in the menu screen.

NEAR/FAR Buttons
Used to change the parameter of the selected menu item.
It also moves the cursor the left of right in the menu screen.

. Rear Body

#1

#2
#3
#4
#5

#6

Line Color

No.

Function

#1

RED

DC12V/AC24V(H)

ORANGE

GND/AC24V(N)

#3

BLACK

GND(VIDEO)

YELLOW

VIDEO OUT

#5

#2

#4

#6

GREEN

RS-485 (+)

BROWN

RS-485 (-)

VIDEO

TELE

WIDE

NEAR

FAR

M

EN

U

6. Remote Controller Operation

Receiver

Remote Control

1

2

3

4

Power
DC 12V, 500mA

RS-485 Signal

- White Terminal :
- Black Terminal :

Camera Selection

- After camera connects with receiver,

firstly check camera I.D.

Menu (PROG): Shows / Hides Menu.

Moves up and down items.

(TELE):
(WIDE):

- Press camera I.D. number(1~39 buttons)

on the top of wireless remote controller.

Caution : Usually camera I.D. number

are selected from No.1 to No.39.

over I.D. No.40, you will have a use limit.

- Initial camera I.D. number is set up No.0

when it takes out of manufacturer's warehouse.

Example: ZOOM IN

I.D. No.5: Press 5 +<TELE>

I.D. No.15: Press <F1>+ 5 +<TELE>

I.D. No.24: Press <F2>+ 4 +<TELE>

I.D. No.34: Press <F3>+ 4 +<TELE>

Set data for the selected items.

(NEAR):
(FAR):

F1

NEAR

FAR

FOCUS

F3

WIDE

F2

TELE

ZOOM

AUTO

SEQ

PAN

PROG

A

7

4

1

6

9

A

0

8

5

3

2

The remote controller is optional item.

Cable Connection (Pelco-D/ RS-485)

Receiver &

Remote Control

Pelco-D Keyboard

DVR System

Signal (RS-485)

FUNCTION

OSD Format

DESCRIPTION

1

2

3

4

Focus Mode

Mirror Mode

Back Light

WBC Mode

5

Shutter
Speed

Non display

Non display

Non display

Non display

Normal shutter (NTSC:1/60 PAL:1/50)
8 variable.

7

Wait Mode

Wait

Indicates the camera stand-by mode.
until the camera power turns ON.

8.1 Sharpness

Adjustment

Mode Display

8.2 Brightness

Adjustment

Mode Display

8

Zoom
Display

x22

:

Optical Zoom only mode

x44

:

Digital Zoom x 2 mode

x220

:

Digital Zoom x 10 mode

6

Camera ID

After input the identification number to each camera,
Multi-point control is available. (000~255)

Automatic focus mode

Manual focus mode

No screen inverted

Screen is inverted to the left or right

Back Light compensation off

Back Light compensation mode

White Balance AUTO

Push Auto White Balance: In this mode
"Menu key" pressed, the white point traced
automatically (PWB Auto Mode), "Menu Key"
released, the white point preserved currently
(PWB Manual Mode).

Non display

1 / 125
1 / 10000

x18

x10

SHP

X10000 ID 255

WAIT

X132

1

2

3

4

5

6

7

8

4. WBC(White Balance Control) Display
See Page 17.

6. Camera ID Display
See Page 17.

5. Shutter Speed
Use to select the shutter speed.

7. Wait Mode
Indicates the camera stand-by mode
until the camera power turns on.

8. Example of Zoom, Brightness,
Sharpness Display
See Page 17.

2. Mirror
When IMAGE MIRROR is ON state. The
image is displayed in the opposite direction.
The appear during the mirror mode.

1. Focus
The appear during the focus manual
mode.

3. Back light Display
In case the excessive light is behind the
center object, it is necessary to prevent
the center object from too much
darkness. Turn the BACK LIGHT ON,
then the center object is not influenced
by the back light.

MENU

7 ZOOM START
8 ZOOM STOP
9 BRIGHTNESS
10 SHARPNESS
11 FOCUS
12 PROTOCOL
13 INIT SET
END

1
220
48
10
AUTO
DEF
ON

NO

NAME

FUNCTION

1

BACKLIGHT

Use to select BLC mode.

OFFㅡㅡ>ON

2

5

SHUTTER

Use to select the shutter speed 8 steps.

NORMAL(NTSC:1/60, PAL:1/50),1/125,1/250,---,1/10000

7

ZOOM START

Use to change the zoom start position.

8

ZOOM STOP

Use to change the zoom stop position.

9

BRIGHTNESS

Use to change the brightness of scene (0~48).

10 SHARPNESS

Use to change the contour of scene (0~15).

11 FOCUS

.

AUTO : Set the focus mode to Auto mode.

.

PUSH AUTO : Set the focus mode to Push Auto mode.

12 PROTOCOL

.

DEF : Default

.

P / D : Pelco-D

13 INIT SET

Set the initial mode ON, the changed data are renewed.

Reset the data to its shipping condition.

6

CAMERA ID

To connect a large number of camera, identification

number can be assigned to each camera control easily.

(OFF, 1-255 : total number of ID is 256)

CAUTION : Set the ID number of camera, then

the ID number is displayed continuously.

3

4

WB CONTROL

.

AUTO : Maintain best color condition by controlling

the change of color automatically.

WB Range 2800˚K ~ 8000˚K

.

PUSH AUTO(PWB) : Can find White Balance exactly

in case precise WB maintenance

is needed under any environment.

--Turn the AUTO mode, WB acts automatically.

--Turn the PUSH AUTO mode, WB doesn't act.

SLOW SHUTTER

Use under very low light condition for full color

surveillance.

OFFㅡㅡ>FLD2ㅡㅡ>ㅡㅡㅡ>FLD128

DAY & NIGHT

Use under low light condition for continuous

surveillance.

Autoㅡㅡ>ONㅡㅡ>OFF

Power On

Function

MSG

BYTE 1

0xFF

BYTE 2
CamID

BYTE 3

0x88

BYTE 4

0x00

BYTE 5

0x00

BYTE 6

0x00

BYTE 7

Checksum

Power Off

Function

MSG

BYTE 1

0xFF

BYTE 2
CamID

BYTE 3

0x08

BYTE 4

0x00

BYTE 5

0x00

BYTE 6

0x00

BYTE 7

Checksum

Pelco D Stop

Function

MSG

BYTE 1

0xFF

BYTE 2
CamID

BYTE 3

0x00

BYTE 4

0x00

BYTE 5

BYTE 6

BYTE 7

Checksum

Menu On / Off

Function

MSG

BYTE 1

0xFF

BYTE 2
CamID

BYTE 3

0x40

BYTE 4

0x00

BYTE 5

0x00

BYTE 6

0x00

BYTE 7

Checksum

Focus Far

Function

MSG

BYTE 1

0xFF

BYTE 2
CamID

BYTE 3

0x00

BYTE 4

0x80

BYTE 5

0x00

BYTE 6

0x00

BYTE 7

Checksum

Focus Near

Function

MSG

BYTE 1

0xFF

BYTE 2
CamID

BYTE 3

0x01

BYTE 4

0x00

BYTE 5

0x00

BYTE 6

0x00

BYTE 7

Checksum

Zoom Wide

Function

MSG

BYTE 1

0xFF

BYTE 2
CamID

BYTE 3

0x00

BYTE 4

0x40

BYTE 5

0x00

BYTE 6

0x00

BYTE 7

Checksum

Zoom Tele

Function

MSG

BYTE 1

0xFF

BYTE 2
CamID

BYTE 3

0x00

BYTE 4

0x20

BYTE 5

0x00

BYTE 6

0x00

BYTE 7

Checksum

PELCO "D" Byte Format

Command Message

-RS-485,2400bps,1 Start bit,8 data bits,1 stop bit,no parity

Menu On / Off

Function

MSG

BYTE 1

0xFF

BYTE 2
CamID

BYTE 3

0x00

BYTE 4

0x23

BYTE 5

0x00

BYTE 6

0x5F

BYTE 7

Checksum

Menu On / Off

Function

MSG

BYTE 1

0xFF

BYTE 2
CamID

BYTE 3

0x00

BYTE 4

0x03

BYTE 5

0x00

BYTE 6

0x62

BYTE 7

Checksum

Pelco Keyboard (95+ PATTERN)

V/D Keyboard (Set Preset + 98)

Don't care

10. Communication Protocol

12. Specficications

PAL

NTSC

Signal System

Scanning System

Horizontal Scanning Frequency

Vertical Scanning Frequency

Pick-up Device

Total Pixels

Effective Pixels

Horizontal Resolution

S/N Ratio

Lens

Minimum Illumination
(30IRE)

Synchronization

Signal Output

Operating Temperature

Storage Temperature

Power
Consumption

Dimensions (WxHxD)

Weight

2 : 1 Interlace

15.734 kHz 15.625kHz

59.94 Hz 50 Hz

1/4 Inch SONY Super HAD CCD / EX-View CCD

811(H) x 508(V) 410K 795(H) x 596(V) 470K

768(H) x 494(V) 380K 752(H) x 582(V) 440K

480 TV lines

More than 48dB (AGC off)

22x Zoom Video AF

(F1.6(W), F3.7(T) f = 3.9~85.8mm)

1 Lux (Color) ,

0.001 Lux (DSS 128 FLD)

Internal

1Vp-p Composite Output with 75Ω Terminated

-10℃~+45℃ / -30℃~+45℃ (with Heater)

-20℃~+65℃

AC 24V (24~28V) / DC 12V (DC 9V~15V)

Max. 8W (AC 24V) / 9.6W (DC 12V)

110.8 x 218.6 x 325.7 mm

Approx 1.6kg

On-Screen Display

OSD

OSD

220x Zoom

/

TE

LE

/ W

ID

E

Move up and down

using the TELE/

WIDE button.

Can be changed

using the /

button.

MENU

1 BACKLIGHT
2 SLOW SHUTTER
3 DAY / NIGHT
4 WB CONTROL
5 SHUTTER
6 CAMERA

OFF
FLD24
OFF
AUTO
1/10000
123

OWNER'S MANUAL

COLOR ZOOM CAMERA SERIES

with DAY & NIGHT

DSS

DSS

Weatherproof

Day & Night Color Camera

Weatherproof

Day & Night Color Camera

Digital Slow Shutter

•P

ow

erf

ul

Zo

om

in

g F

un

ct

io

n

M

a

x

.

2

2

0

x

Z

o

o

m

(2

2x

O

pt

ica

l/10

x Digi

tal)

On-Screen Display

OSD

OSD

220x Zoom

This manual is related to the following products:
