5. Specifications
IGP1000F Specifications
Camera
Signal System Progressive image processing
Scanning System 4:3 Progressive
Image Sensor Progressive CCD Sensor
Sync. System Internal
Effective Pixels Number 659 (H) x 494(V) 330K
Video Output Level Select NTSC/PAL 1.0Vp-p (BNC 75Ω, composite)
Lens C/CS Mount, DC Iris, Manual Iris
Flickerless On/Off
White Balance
Auto/Manual
Exposure Auto/Manual
Day & Night System
ICR
Min. Illumination 1 Lux (Color), 0.7 Lux (B/W), F1.2, DSS on
Electronic Shutter Speed
NTSC : 1/10 ~ 1/600 (8 Step)
PAL : 1/9 ~ 1/500 (8 Step)
System
Main Processors 32bit Embedded CPU with Linux
System Memory NAND Flash Memory : 64MByte, 128MB DDR Memory
Video / Audio
Compression MJPEG / MPEG4 / H.264
Frame rate
Single Mode : Main(H.264@30fps) *VGA
Dual Mode : Main(H.264/MPEG4, 30fps), Second(MPJEG) *VGA
Resolution VGA (640 x 480), QVGA (320 x 240)
Video streaming
MJPEG / MPEG4(or H.264) Dual mode
Constant and variable bit rate in MPEG4 (128kbps ~ 3M bps)
Controllable frame rate and bandwidth
Image settings
Compression level setting
Configurable Brightness, Sharpness, White Balance
Audio Two-way (Full duplex / ADPCM G.726)
Network
Protocol
Ipv4, HTTP, HTTPs, UDP, TCP, RTSP, RTP, SMTP, FTP, ICMP, DHCP, UPnP, Bonjour,
ARP, DNS, DynDNS, NTP, IGMP(Multicast) *) OnVif
Supported DDNS
1. CNB DDNS 2. DynDNS.org
3. Reference code with SDK
Video access from
Web browser
Camera live view for up to 10 clients
LAN Interface Ethernet 10/100 Base-T (RJ-45 Type)
Support PoE Standard IEEE 802.3af supported
Security
Access level setup Multiple user access levels with password protection
Network Security IP Filtering
Alarm and Event
Management
Image detection Motion detection (Select 3 Regions - each area)
Sensor detection Sensor In, Scheduling, Alarm out
After Event process JPEG Image upload over FTP server / SMTP (E-mail server)
Local storage
JPEG Image write to Internal & SD card memory
- Internal memory : Max 32MByte / SD memory : Support size Max 4GByte
Pre / Post alarm
Detail time-set : Max Pre alarm 5 sec / Post alarm 8 sec
Local storage (Internal memory or SD card memory : JPEG image)
Applications
Browser Internet Explorer 6.0 or later
Monitoring Application
Web Viewer (Window Web Browser Base)
Live view for up to 10 user clients
Video Snapshot to file (JPEG)
XNET NVR, CNB CMS and Utility (IP-Installer, etc)
