XNET User Manual
28 / 50
ITEM DESCRIPTION
Video Out
Enable Video
Out
Turns the Video Out feature on or off.
less.>
Video Format
Selects Video format at Video Out terminal between
NTSC and PAL.
White
Balance
White Balance
Configures Video’s White Balance.
White Balance means balancing color temperature by adjusting Red and
Blue level.
Auto mode will adjust White Balance automatically, while manual mode will
adjust white balance level according to manually configured Red and Blue
level.
Red Control
Select Video’s Red level between brightness of 0 and 255.
This can only be enabled when White Balance is configured as Manual
mode.
Blue Control
Select Video’s Blue level between brightness of 0 and 255.
This can only be enabled when White Balance is configured as Manual
mode.
Video
Setting
Brightness Select Brightness of Video between 0 and 12.
Saturation Select Color Saturation of Video between 0 and 14.
Sharpness Select Sharpness of Video between contrast 0 and 10.
DNR Select DNR level between 0 and 15
3DNR Select 3DNR level on or off.
BLC
Turns Back Light Compensation on or off.
When enabled, the images will not be saturated even when too much light
comes into the Lens.
Day/Night Selects between Auto/Day/Night for IR LED.
Day/Night
Delay
Select the Delay Time for IR LED operation.
Gain &
Shutter
Condition
Exposure
Configures Exposure of Video.
Exposure means to control brightness of video by adjusting Gain value.
In auto mode, Exposure will automatically be adjusted to proper level
according to its selected Indoor or Outdoor type. In Manual mode,
Exposure will be adjusted to the gain value entered.
Lens Select Auto Exposure mode.
Gain Control Select Gain level of Video between 1 – 15 only in Manual Exposure mode.
Gain Control
Limit
Select the Max Gain level of Video between 1 – 15 only in Auto Exposure
mode.
