CNB IGC2050F User Manual
Page 9
XNET User Manual
9 / 50
ITEM
DESCRIPTION
Capture -
Captures the still image and displays on a pop-up window.
[Save to] c:₩xNetCapture
Setting -
Opens up Basic Setup Page.
Setup page for each XNET feature can be opened from this Menu
screen.
(Please refer to 1.4 for detail)
PTZ -
Opens up PTZ page.
This page can set up digital PTZ of the network camera and control
of PTZ movement. (Please refer to 1.8 for detail)
Live View
-
Open up Motion Index View page.
Index View Page will display Video as well as setting up Stream
Protocol (TCP / UDP) and Codec (when using Dual Stream).
Stream Protocol
-
A Stream Protocol can be selected when selecting EditBox
(RTP over TCP/RTP over UDP)
Dual Stream
Service
Main Stream
When this box is checked, Main Stream Video is displayed.
Sub Stream
When this box is checked, Sub Stream Video is displayed.
(H.264/MJPEG) Dual-Codec needs to be enabled in Video Setup Page
in order for Sub Stream Video to be displayed.
(Please refer to 1.10 for detail)
