Clock Audio PP 2 User Manual
Pp-2

PP-2
P R O F E S S I O N A L M I C R O P H O N E S Y S T E M S
Designed for use with all condenser microphones at installations where there is no current
phantom power supply available.
www.clockaudio.com
Specifications
48V dual channel phantom power supply.
Switchable mains input supply to facilitate use on
110VAC / 230VAC mains supplies.
Red led power indicator.
Standard XLR microphone Input / Output connectors.
Dimensions W165mm H45mm D110mm.
Weight 0.82Kgs
Front panel Connections:
Power On/Off
switch.
Rear panel Connections:
Mains In
110VAC /
230VAC Input
Voltage selector
switch.
Fuse 500mA.
Male XLR Outputs
Channel 2 and 1
Connect to mixer /
amplifier source.
Female XLR Microphone
Inputs Channel 2 and 1
Warning This is a mains
operated device. Do not
operate in wet or damp
conditions. When cleaning
the unit remove the plug
from the mains socket.
Do not dispose of with your regular household
waste. Observe local laws and regulations for waste
disposal.
Fuse replacement 3 Amp
