Hardware Description
LED
Indication
Power
Steady red during boot up process.
Steady blue after boot sequence has completed.
Flashing purple during firmware upgrade.
Network
Flash yellow while Network activity.
MicroSD Card
Steady yellow means MicroSD card ready.
Flash yellow while accessing MicroSD card.
