Specifications
1.1 Dimensions
Figure 1 Dimensions
5 jkl 6 mno 4 ghi 8 tuv wxyz 9 7 pqrs
2 abc 3 def 1
0
Y 1
X
Z
Y 2
BÜHLER 3010
BÜHLER 4010
BÜHLER 6010
BÜHLER 4210
BÜHLER 4410 (2–12 Flaschen)
BÜHLER 4410 (24 Flaschen)
BÜHLER 4210 (23 Flaschen)
BÜHLER 4110
mm [in.]
Y 1
1100 [43.3]
1325 [52.2]
1690 [66.5]
1325 [52.2]
1325 [52.2]
1415 [55.7]
1415 [55.7]
1475 [58.1]
mm [in.]
X
760 [30]
605 [23.8]
1200 [47.2]
605 [23.8]
605 [23.8]
715 [28.1]
715 [28.1]
605 [23.8]
mm [in.]
Y 2
1640 [64.6]
1895 [74.6]
2260 [89]
1895 [74.6]
1895 [74.6]
2120 [83.5]
2120 [83.5]
2030 [79.9]
mm [in.]
Z
725 [28.5]
645 [25.4]
645 [25.4]
645 [25.4]
810 [31.9]
810 [31.9]
645 [25.4]
645 [25.4]
(23 bottles)
(2–12 bottles)
(24 bottles)
