Hach-Lange BUHLER 1027, 1029, 2000 Portable Sampler - Manual (Page 28)

28
Installation
3.3.4 Remove the top part of the housing (2000)
3.3.5 Prepare the bottle compartments
Note: The sample distributor plate works correctly in all four of its potential positions.
Note: The housing base of the bottle compartment features numbers so that the individual bottles
can be assigned with a number.
Figure 30 Remove the top part of the housing (2000)
2
1
20
15
11
6
1
Figure 31 Place the empty bottles into the bottle compartment
2 1 3
20
15
11
6
1
20
15
11
6
1
20
15
11
6
1
