Measuring range 2 to 14 pH
Operating temp. 0 to 80 °C
Max. pressure 2 bar
Reference element cartridge
Diaphragm open circular
Electrolyte solid
Body material glass
Thread PG 13,5
Connector MP-4
Temperature sensor Pt 1000
Min. immersion depth 12 mm
5
GB
Storage
Place the electrode in the storage protec-
tor
with KCl + glycerine.
Life of an electrode
The average life expectancy of a pH proc-
ess electrode oscillates between 6 or 12
months, depending on the working con-
ditions.
Electrodes exposed to high temperatures
do not last as long. Very alkaline mediums
also reduces the life span of electrodes.
If an electrode has too short life span,
less than three months, ask us about it.
Probably there is a more suitable elec-
trode for the application.
Specifications
Applications
Dirty water, with mud, waste water, etc.
Limitations
Solutions with pH < 2, very clean water,
distilled and de-mineralised water.
Temperature > 80ºC. Pressure > 2 bar.
CERTIFICATE OF QUALITY
The attached electrode 53 37 T has
passed the quality test and follows the
next specifications:
• Asymmetry potential < ± 15 mV.
• Sensitivity, pH 4 to 7 (at 25 ˚C) > 98%.
• Response time, pH 4 to 7 < 20 s.
• Temperature error 0.5 ºC.
