32
Operating Information
4.4.6 Clearing stored values
To clear all the values stored in the instrument via the WinLog97 program, choose the Clear
Data
command from the Logger menu. Since this action will clear the storage memory of the
instrument, a warning appears first.
Choose OK to bring up the next dialog box to confirm the clear action.
Choose Clear to start the memory clear operation. A message, Reset should be completed
appears in this box when the task is finished.
Note: You can accomplish the same thing passively, by simply allowing the analyzer to overwrite a set of
stored values with new ones.
4.5 Monitoring measurements in real-time
You may wish to analyze a particular sampling point via the WinLog97 program's Monitoring
menu. To use this Monitoring chart, the instrument must be connected to your PC.
Choose Monitoring from the WinLog97 menu to bring up a chart display.
The Monitoring chart shows the gas concentration (in blue), temperature (in red), and pressure
(in green) as the sample is being measured by the 3650Ex instrument. The chart is updated
directly from instrument measurements, at a rate determined by the time scale set in the
TIMEBASE
box at the lower right corner of the chart.
