N O T I C E
Potential instrument damage. Delicate internal electronic components can be damaged by static electricity,
resulting in degraded performance or eventual failure.
To install the module and connect the sensor, refer to the illustrated steps that follow and the wiring
table
Be sure to connect all sensor ground/shield wires to the controller enclosure grounding screws.
Note: If the sensor cable is not long enough to reach the controller, an interconnect cable and junction box are
required to extend the distance.
Table 1 Dissolved oxygen and oxygen scavenger sensor wiring
Terminal
Description
Dissolved oxygen
Oxygen scavenger
1
Temp +
Black
Black
2
Temp -
Blue
Blue
3
—
—
—
4
—
—
—
5
Ground
Green
Green
6
Earth
Yellow
Yellow
7
—
—
—
8
—
—
—
9
Working electrode
White
White
10
Counter electrode
Red
Gray
11
Reference electrode
—
Transparent
12
—
—
—
In Step 3 of the following sequence, set the switch as follows:
Switch Setting
Description
Setting 1
Dissolved oxygen
Setting 2
Oxygen scavenger
English 5
