WAP354H
Wireless 802.11a/b/g 5-Port High Power Access Point
Description
Wireless 802.11a/b/g Access Point, WAP354H, comes with 5
Ethernet ports and high-speed wireless connection to link all
types of networking device together.
To ensure the highest level of security, WAP354H provides
64/128 bit WEP, WPA, WPA2 encryption, IEEE 802.1x and MAC
Address Filter to prevent unauthorized PCs from accessing your
wireless network.
With a web-based management interface, setting up and
maintaining your network is easy and can be done from any
computer on the network
Specification
Standards IEEE 802.11 a/b/g standards compliant
Antenna Dual Band Detachable Dipole Antenna (RP-SMA 2dBi)
Frequency Range
802.11b/g
USA (FCC): 2.412GHz ~ 2.462GHz
Europe (ETSI): 2.412GHz ~ 2.472 GHz
Japan (TELEC): 2.412GHz ~ 2.483GHz
802.11a
U-NII: 5.15 ~ 5.35 GHz; 5.725 ~ 5.825 GHz
ISM: 5.725 ~ 5.850 GHz
DSRC: 5.850 ~ 5.925 GHz
Europe(ETSI): 5.15~5.35 GHz; 5.47~5.725 GHz
Japan (TELEC): 4.90 ~ 5.00 GHz; 5.03 ~ 5.091 GHz
Number of Selectable
Channels
802.11b/g: USA (FCC) 11 channels; EU (ETSI) 13 channels; Japan
(TELEC) 14 channels
802.11a: USA (FCC) 12 channels; EU (ETSI) 19 channels; Japan
(TELEC) 4 channels
Data Rate
802.11b: 1, 2, 5.5, 11Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps
802.11a: 6, 9, 12, 18, 24, 36, 48, 54Mbps
Coverage Area
Indoor: up to 100M
Outdoor: up to 300M
Transmit Power
11a OFDM: 15 ~ 17dBm ; 11g OFDM: 15 ~ 17dBm
11b CCK: 18 ~ 20dBm
Receiver Sensitivity
11a -65dBm at 54Mbps, 10% PER;
11b -80dBm at 11Mbps, 8% PER ;
11g -65dBm at 54Mbps, 10% PER
Power Requirement 12V / 1A
Certifications: FCC, CE
Features
Support 802.11a/b/g Standards
Security: WEP 64/128, WPA, WPA2, 802.1x and 802.11i
AP, WDS (Bridge + Repeater), or Client Mode
Advanced Quality of Service (QoS) - 802.11e, WMM
OS support: Win98/SE/ME/2000/XP/CE, Linux, MAC OSX
Applications
