1.
Refer to the Manual Drain Valve Tube Installation Diagram shown
below. Push the drain tube onto the elbow and secure with gear clamp
using a slotted screwdriver. Run the drain tube to a container or suitable
floor drain like the sewer.
Manual Drain Valve Tube Installation Diagram
Manual Drain Valve Tube Installation
NOTE: If you have purchased the Automatic Electric Drain Kit, Go to the
PWS AED-1 Automatic Electric Drain Kit Installation section of the
guide and install it now.
TUBE
TO SEWER
GEAR CLAMP (SHIPPED IN PARTS BOX)
BACK OF THE
DISTILLER
BALL VALVE ASSEMBLY
