Hydrotech Precision-PWS 45-75, AED-2 & APK-4 SERIES 0004 0002 0001 REPLACEMENT PARTS MANUAL User Manual
Page 4
094150, Exploded Parts List
Holding Tank Assembly, 45-75
Item
# Part
# Description Qty
1
520149
Dual Micro Switches WA, Short Arm
1
2
520147 Shim,
Micro
Switch,
Lexan
2
3 025000 Nut,
Hex,
SS,
¼”-20 2
4
520146 Cover,
Level
Sensor,
CD
1
5 520159 Cap
Nut
WA,
#6-32
2
6
010000
Screw, Sheet Metal, SS, #10-12 X 1/2”
3
7 026003 Nut,
Kep,
Plated,
#4-40
4
8 054002 Stain
Relief,
7K-2
1
9
520174
Harness, Circular Plug, Level Sensor, CD
1
10
520160
Level Sensor Box WA, CD
1
11
080187
Float
2
12
520115 Leg
WA,
Rear
Right,
CD
1
13
080126
Appliance Foot, 5/16” X 1-1/2”
2
14
012008
Screw, Machine, SS, #10-24 X 3/8” Oval
16
15
520117 Leg
WA,
Front
Right,
CD
1
16
034023 Cap,
Grey,
1/2FPT
4
17
520112 Holding
Tank
WA,
45-75
1
18
520116 Leg
WA,
Front
Left,
CD
1
19
080174 Sight,
Gauge
Assembly,
40”
1
20
520248 Lid
Assembly,
Holding
Tank
1
21
520157 Rod
WA,
1/8”
X
39-1/4”
1
22
520176 Filter
Housing
WA,
2-1/2”,
CD
1
23
012003
Screw, Machine, Plated, #4-40 X 3/4”
2
24
400006 Micro
Switch,
Short
Arm
1
25
520114 Leg
WA,
Rear
Left,
CD
1
26
520168 Rod
WA,
1/8”
X
2”
1
27
520144 Gasket,
Level
Sensor
Box,
CD
1
28
520178 Filter
Cap
WA,
2-1/2”
1
29
054005
Bushing, Wire Plastic, 5/8” Hole
2
30
016017
Screw, Nylon, #4-40 X 1.25”, Fil Hd
2
04/08/04
Page 4
097047-S4B
