Wiring list – precision pure, 45-75, part # 52012 – Hydrotech Precision-PWS 45-75, AED-2 & APK-4 SERIES 0004 0002 0001 REPLACEMENT PARTS MANUAL User Manual
Page 26
Wiring List – Precision Pure, 45-75, Part # 520129
No. Part# Color Ga Length From Conn.
ToConn.
From Location
To Location
1
520118 GRN 10 6"
#10RING#10-#12
POWER CORD
GROUND
POWER CORD
2
520118 BLK
10 6"
#10RING#10-#12
POWER CORD
TERMINAL BLOCK #3
POWER CORD
3
520118 WHT 10 6"
#10RING#10-#12
POWER CORD
TERMINAL BLOCK #2
POWER CORD
4
520118 RED 10 6"
#10RING#10-#12
POWER CORD
TERMINAL BLOCK #1
POWER CORD
5
095077 BLK
10 28"
#10RING#10-#12
#10RING#10-#12
BREAKER SWITCH 30A
TERMINAL BLOCK
6
095078 RED 10 28"
#10RING#10-#12
#10RING#10-#12
BREAKER SWITCH 30A
TERMINAL BLOCK
7
095079 BLK
10 10"
F250#10-#12
#10RING#10-#12
RELAY #4
BREAKER SWITCH 30A
8
095080 RED 10 10"
F250#10-#12
#10RING#10-#12
RELAY #8
BREAKER SWITCH 30A
9
095081 BLK
10 12"
F250#10-#12
#10RING#10-#12
RESET SWITCH #1
RELAY #2
10 095082 WHT 10 5"
#10RING#10-#12
#10RING#10-#12
HEATING ELEMENT 1 A
RESET SWITCH #2
11 095083 RED 10 11"
#10RING#10-#12
F250#10-#12
HEATING ELEMENT 1 B
RELAY #6
12 095084 WHT 10 6"
#10RING#10-#12
#10RING#10-#12
HEATING ELEMENT 2 A
HEATING ELEMENT 1 A
13 095085 BLK
10 7"
#10RING#10-#12
#10RING#10-#12
HEATING ELEMENT 2 B
HEATING ELEMENT 1 B
14 095041 ORG 16 5"
F250#14-#16
#10RING#14-#16
HOURMETER
HEATING ELEMENT 2 B
15 095042 BRN 16 5"
F250#14-#16
#10RING#14-#16
HOURMETER
HEATING ELEMENT 2 A
16 095043 BRN 16 12"
#10RING#14-#16
#10RING#14-#16
RESET SWITCH #3
BREAKER SWITCH 30A
17 095044 BLK
16 19"
F250#14-#16
#10RING#14-#16
TERMINAL BLOCK #3 BLK
RESET SWITCH #4
18 095045 RED 16 13"
F250#14-#16
#10RING#14-#16
TERMINAL BLOCK #9 RED
BREAKER SWITCH 30A
19 095046 BRN 16 12"
F187#14-#16
F250#14-#16
LOWER MICROSWITCH NC
RELAY #0
20 095047 ORG 16 13"
BARE
PIGG
FAN MOTOR-N
RELAY #6
21 095048 GRN 16 27"
PIGG
PIGG
SOLENOID VALVE A
RELAY #1
22 095049 WHT 16 10"
FPIN
F250#14-#16
HOLDING
TANK RECEPTACLE #2 SOLENOID VALVE A
23 095050 BRN 16 33"
F250#14-#16
F250#14-#16
WATER SWITCH #6
SOLENOID VALVE B
24 095051 BLU
16 20"
F250#14-#16
BARE
FAN SWITCH #3
FAN MOTOR-L
25
095052
GRN
16
17"
F250#14-#16 F250#14-#16 HEATER SWITCH #2
TERMINAL BLOCK #1 BLK
26 095053 BLK
16 14"
F250#14-#16
F250#14-#16
WATER SWITCH #2
TERMINAL BLOCK #2 BLK
27 095054 BRN 16 13"
F250#14-#16
F250#14-#16
PUMP SWITCH #2
TERMINAL BLOCK #4 BLK
28 095055 ORG 16 30"
FPIN
F250#14-#16
HOLDING TANK RECEPTACLE #1 TERMINAL BLOCK #11 RED
29
095056
ORG
16
14"
F250#14-#16 F187#14-#16 HEATER SWITCH #3
LOWER MICROSWITCH COM
30 095040 BLK
16 5"
F250#14-#16
PIGG
FAN SWITCH #2
HEATER SWITCH #3
31 095057 YLW 16 16"
F250#14-#16
F187#14-#16
WATER SWITCH #3
UPPER MICROSWITCH COM
32 095040 BLK
16 5"
F250#14-#16
PIGG
HEATER SWITCH #7
FAN SWITCH #7
33 095058 BLK
16 29"
FPIN
F250#14-#16
HOLDING TANK RECEPTACLE #4 PUMP SWITCH #3
34 095059 YLW 16 10"
F250#14-#16
PIGG
FAN SWITCH #7
RELAY #6
35 095060 BLK
16 7"
PIGG
FPIN
FUSE SIDE
PUMP RECEPTACLE #2
36 095061 YLW 16 5"
FPIN
F250#14-#16
HOLDING TANK RECEPTACLE #5 FUSE END
37 095062 BLU
16 29"
F250#14-#16
FPIN
TERMINAL BLOCK #11 RED
HOLDING TANK RECEPTACLE #3
38 095063 GRN 16 4"
FPIN
#10RING#14-#16
HOLDING
TANK RECEPTACLE #7 GROUND DISTILLER BODY
39 095064 GRN 16 7"
FPIN
#10RING#14-#16
PUMP RECEPTACLE #7
GROUND HOLDING TANK BODY
40 095065 GRN 16 7"
MPIN
#10RING#14-#16
PUMP PLUG #7
GROUND PUMP BOX
41 095066 YLW 16 14"
F250#14-#16
F250#14-#16
HEATER SWITCH #8
TERMINAL BLOCK #10 RED
42 095010 WHT 16 3"
PIGG
F250#14-#16
HEATER SWITCH #3
HEATER SWITCH #6
43 095010 WHT 16 3"
PIGG
F250#14-#16
FAN SWITCH #3
FAN SWITCH #6
44 095086 BLU
16 7"
F250#14-#16
F250#14-#16
WATER SWITCH #7
RELAY #1
45 095067 RED 16 14"
PIGG
F187#14-#16
WATER SWITCH #6
UPPER MICROSWITCH NC
46 520174 GRN 18 10"
MPIN
#1/4RING#18-#22
HOLDING TANK PLUG #7
GROUND HOLDING TANK BODY
47 095069 WHT 16 14"
F250#14-#16
F250#14-#16
TERMINAL BLOCK #12 RED
PUMP SWITCH #6
48
095070
BLU
16
30"
F250#14-#16 F250#14-#16 FUSE
SIDE
PUMP
SWITCH
#7
49 095040 BLK
16 5"
F250#14-#16
PIGG
FAN SWITCH #8
HEATER SWITCH #8
50 095040 BLK
16 5"
F250#14-#16
PIGG
WATER SWITCH #8
FAN SWITCH #8
51 095040 BLK
16 5"
F250#14-#16
PIGG
PUMP SWITCH #8
WATER SWITCH #8
52 520174 ORG 18 10"
F187#18-#22
MPIN
HT MICROSWITCH NC
HOLDING TANK PLUG #1
53 520174 WHT 18 10"
F187#18-#22
MPIN
HT MICROSWITCH COM
HOLDING TANK PLUG #2
54 520174 BLK
18 10"
F187#18-#22
MPIN
PUMP #1 MICROSWITCH NO
HOLDING TANK PLUG #4
55 520174 YLW 18 10"
F187#18-#22
MPIN
PUMP #1 MICROSWITCH COM
HOLDING TANK PLUG #5
56 520174 BLU
18 10"
F187#18-#22
MPIN
PUMP #2 MICROSWITCH COM
HOLDING TANK PLUG #3
57 520174 RED 18 10"
F187#18-#22
MPIN
PUMP #2 MICROSWITCH NO
HOLDING TANK PLUG #6
58 095087 RED 16 6"
FPIN
FPIN
PUMP RECEPTACLE #6
HOLDING TANK RECEPTACLE #6
59 520150 BLK 18 26"
#10RING#18-#22
DRAIN
RECEPTACLE BREAKER SWITCH 30A
DRAIN RECEPTACLE (SMOOTH)
60 520150 BLK
18 19"
PIGG
DRAIN RECEPTACLE RELAY #1
DRAIN RECEPTACLE (RIBBED)
04/08/04
Page 26
097047-S4B
