6" Hydra-Gate Overall Dimensions

167 Stock Street, Nesquehoning, PA USA

Phone: 570-645-3779 Fax: 570-645-4061

Website: www.hydra-tech.com

Each Hydra-Gate Slurry Mixing Valve unit includes:

(1) Diverter Valve assy.
(1) Control Valve assy.
(1) Pair, 1/4" x 50 ft. Hydraulic Hose assy. (CV to DV)
(1) Pair, 1/4" x 10 ft. Hydraulic Hose assy. (CV to HPU)

Discharge Hose Connector Fittings

We have connector fittings that will allow you to connect to the most popular hose fittings:

Cam-Lock (Cam & Groove), Bauer (Ball & Socket) and Flanges

Optional Accessories

Tee Adapter kits ( Allows connection to power units without modifications).

Kit includes Tee Adapters for connections to the pressure and

return ports with Quick -Disconnect couplings

Hydra-Gate Components and Options

OUT 'A'

OUT 'B'

Diverter Valve

Control Valve with Hoses

1" Tee Adapter Kit

1/2" kit Part# 5505030
3/4" kit Part# 5505031
1" kit Part# 5505052
