AVerMedia LX5000 User’s Manual

Direction buttons

Use these buttons to navigate the camera’s directional focus during

surveillance.

PTZ Camera Number

You may view the status of each PTZ camera by clicking on the

corresponding PTZ Camera Number buttons. Highlighted cameras

indicate that the PTZ cameras are connected. The gray (disabled)

squares indicate that no PTZ cameras are operational or no cameras are

installed.

PTZ Setup Menu

Select one of the 16 preset positions from the Preset

Position Number buttons, then select the speed from one of the 4

Speed buttons (the higher the level, the faster the speed), and then

use the Up/Down/Left/Right buttons to adjust the position of the

camera.

Focus in / Focus out: Click these buttons to adjust the

image focus.

Zoom in / Zoom out: Click these buttons to zoom in and

zoom out, enlarging and reducing the image respectively.

Clear

Preset Position Number

Focus in / Focus out

Zoom in / Zoom out

Up / Down / Left / Right

Move Speed

Stay Time

Rotation Speed

Save

AVerMedia LX5000 User’s Manual

Stay Time: Use this setting to configure the stay-time in

seconds (1~8 seconds), which defines the time the camera stays fixed

at its previous or next preset position, depending on your PTZ model,

during Auto Pan.

Rotation Speed: This parameter defines the speed the camera

rotates from the current position to its next preset position. The

rotation speed (degree/second) ranges from 30 per second to 240 per

second in increments of 30 per second.

Save: After completing the steps above, click this button to save

the current preset position settings. Choose the next preset position

and follow the same steps until all desired positions are set. If you

want to continue with another camera, click

to go back to the main

menu of the PTZ Camera and select the new camera.

Clear: Click this button to clear the previous settings for all

preset positions for the current PTZ camera. If you only want to delete

some of the preset positions, you need to click into each preset position,

delete and/or reset new parameters before you click the Save button.

4.3.5

Start Network Service

Press this button: start or stop the internet service. Then, it can

accept the Client to do the remote management through the web viewer

and remote management program. When you press the button one

more time, you can stop the internet faction. The system will ask you to

input the password when you log on or log off. When the system
