Specification
Main Chipset DS2 DSS9010+ DSS7800 + Realtek RTL8306
Standard support UPA DHS (200 Mbps) PLC, IEEE 802.3 & 802.3u.
Interface One Powerline port, four power outlets, four 10/100Mbps Ethernet
ports
Power AC 100~240V/ 50~60Hz/ 10A
Dimension (W x D x L) US type: 141.9mm (W) x 280mm(L) x 48.8mm(H),
EU/UK type: 141.9mm (W) x 280mm(L) x 47.6mm(H).
LED Power: Yellow-Green
Power On: On,
Power Off : Off
Powerline: Yellow-Green
Link: On,
Act: Blink
No-link: Off
1-4 Ethernet: Yellow-Green
Link: On,
Act: Blink
No-link: Off
Surge Energy Rating Up to 1400 Joules
Over Current Protection 10Amps
Operating Temperature 0~40ºC (32~104ºF)
Relative Humidity: 10%~90% non-condensing
Storage Temperature: -10~60ºC (14~140ºF)
Relevant Humidity: 10%~95% non-condensing
C ERTIFICATIONS FCC Part 15, Part B, Class B, CE Class B,
UL 60950-1 / UL 1449 (option), CB (option).
