Global Specialties 1505 User Manual
Page 3
TABLE OF CONTENTS
SECTION
DESCRIPTION
PAGE NO.
1
INTRODUCTION
1
2
SPECIFICATIONS
2
3
DESCRIPTION
3
4
OPERATING INSTRUCTIONS
4
5
SERVICE &
5
WARRANTY INFORMATION
6
CALIBRATION PROCEDURE
7
7
PART LIST & SCHEMATICS
8
8
CIRCUIT DIAGRAM
12
PCB Components
FRONT PANEL
=======================================================================
Reference Designator
Part Description
========================================================================
OUTPUT SOCKETS
SOCKET 1
European ( 230VAC )
SOCKET 2
American ( 115VAC )
SOCKET 3
SLBR4 ( Lekage Red )
SWITCHES
SW1
ON/OFF SPDT 1801 10A/230V
SW2
DPDT Toggle 6A/250V
FUSE
F1
6Amp / 250V S/B
F2
5AMP / 250V S/B
FUSE HOLDERS
FH1
10Amp / 250V R3-11
FH2
10AMP / 250V R3-11
PCB Components
CHASSIS
=======================================================================
Reference Designator
Part Description
========================================================================
TRANSFORMERS
T1
1506 Isolation
T2
1506 Current
T3
1506 DPM
T4
1506 0-120V/4Amp Variable
T5
1506 Voltage Sense
11
