11 2
SECTION - 2
SPECIFICATIONS
LINE INPUT VOLTAGE : 110 - 150V AC, 60Hz
MAXIMUM AC CURRENT
rms
: 20Amps.
peak : 35Amps peak.
MAXIMUM POWER : 1999W.
POWER FACTOR : 0.5 to unity.
CREST FACTOR Volts : 2.5:1 @ 120V AC.
Amps : 1.8:1 @ 20 Amps.
ACCURACY Volts : ±0.8% ±1digit.
Amps : ±1.0% ±2digit.
Watts : ±1.25% ±2digits.
RESOLUTION Volts : 0.1 Volt.
Amps : 0.01 Amp.
Watts : 1.0 Watt.
FREQUENCY RESPONSE : 40Hz To 5KHz.
NUMBER OF DIGITS : 3.5digits
DISPLAY : Green L.E.D. 0.56"high
SIZE ( H X W X D ) : 155mm X 170mm X 215mm
WEIGHT : 2.5Kg. (Approx).
PCB Components 767E/01 PCB REV-01 contd...
=======================================================================
Ref Designator Value
=======================================================================
ICs
IC6 4066
IC8 NOT USED
IC9,10,11 TLO-81CP
IC12 AD736
IC13 NOT USED
IC14 AD736
IC15 AD633
IC16 TLO-81CP
IC17 TLO-81CP
IC18 TLO-81CP
IC19 7812
IC20 7912
IC21,22 7805
PCB Components WD767-SW-0995 PCB REV-01
=======================================================================
Ref Designator Value
=======================================================================
RESISTORS
R1,2 100K,1/4W,5%,MFR
R3 Not Used
R4 1K5,1/4W,5%,MFR
R5 1K5,1/4W,5%,MFR
R6 1K5,1/4W,5%,MFR
R7 1K5,1/4W,5%,MFR
R8 1K5,1/4W,5%,MFR
R9 100K,1/4W,5%,MFR
R10 100K,1/4W,5%,MFR
