SECTION - 1
GENERAL INFORMATION
DESCRIPTION :
Vector model 1522 Digital Wattmeter is an accurate low
cost instrument designed for use in Engneering, Quality
control and Production Test departments to determine the
power consumption of equipments operating directly from
a standard 110 - 150V AC, 60Hz line. Instrument features
large L.E.D. display.
In addition to power measurement, the wattmeter
measures AC (true RMS) voltage and AC (true RMS)
current.
The Digital Wattemeter is easy to operate. Each
measurement function, voltage (V), current (I) or power
(W) is selected by a simple pushbutton switch on the front
panel.
The Digital Wattmeter can be connected to two different
loads. The total load current can be upto 20A maximum.
1
12
PCB Components
WD767-SW-0995 REV-01 contd...
=======================================================================
Ref Designator
Value
=======================================================================
CAPACITORS
C1
0.1uF,50V,CD
C2
10uF,16V,EL,RAD
C3*
0.1uF,50V,CD
TRANSISTORS
Q1
NOT USED
Q2
BC557
Q3
BC557
Q4
BC557
IC's
IC1
4013
IC2
4071
IC3
4071
IC4
4013
LED'S
LED1
Not Used
LED2
5mm,RED
LED3
5mm,RED
LED4
5mm,RED
SWITCHES
SW1
Not Used
SW2
D6 KEY
SW3
D6 KEY
SW4
D6 KEY
CONNECTORS
CON1
2.54mm,5PIN MALE
CON1
2.54mm,5PIN MALE
