SECTION - 2
INSTALLATION
INITIAL INSPECTION :
As soon as the 1315 variable AC/DC source is unpacked,
inspect for any damages that may have occured during
transit. Save all packing material until inspection
is complete. If damage is found, notify the carriers
immediately. Our authorised representative also should be
notified.
PHYSICAL CHECK :
This check should confirm that there are no broken knobs.
The cabinet and panel surfaces should be free of dents.
ELECTRICAL CHECK :
The 1315 variable AC/DC source is shipped ready for
bench operation. It is necessary only to connect the
instrument to a rated input voltage 115V AC / 60 Hz / 5A
source of power and it is ready for operation.
INPUT POWER REQUIREMENTS :
The 1315 variable AC/DC source may be operated
continuously from a 115V AC / 60 Hz power source.
REPACKING FOR SHIPMENT :
To ensure safe shipment of the 1315 variable AC/DC
source, it is recommended that the package designed
for the instrument be used. The original packing
material is reusable.
2
PCB Components
=======================================================================
Ref Designator
Value
=======================================================================
SWITCHES
SW1 ON / OFF SWITCH
10A, 125V, DPST, ILLUMINATED
( T125 ARCOLECTRIC )
SW2 TOGGLE SWITCH 5A, 250V
GENERAL
AUTO TRANSFORMER INPUT 2A / 115V, AC
OUTPUT 5A / 30V, AC
CIRCUIT BREAKER 5A / 125V AC / DC
FUSE HOLDER 10A / 250V, FHB/02
INPUT FUSE 2A / 250V, SLOW BLOW
5
