GV-EV48
January 16, 2014
-2-
Specifications
System Requirements
GV‐ASManager Version
GV‐ASManager V4.1 or later
Hardware
CPU
32‐bit ARM7TDMI
Number of User Cards
40,000 cards
Event Buffer
1,000,000 events and log data
Power
AC 100~250 V , 50~60Hz
RS‐485 Interface
1 RS‐485 interface only for GV‐Readers and GV‐GF Fingerprint Readers (max. 2 readers)
Communication
TCP/IP
GV‐EV48‐24 Floors
24 relay outputs (30VDC, 1A; 125V AC, 0.3A)
Output
GV‐EV48‐48 Floors
48 relay outputs (30VDC, 1A; 125V AC, 0.3A)
Operating Temperature
0~65°C / 32 ~ 149°F
Operating Humidity
10% ~ 90% RH (non‐condensing)
Dimensions (W x H x D)
210 x 170 x 55 mm (8.27 x 6.69 x 2.17 in)
Weight
610 g (1.34 Ib)
Certification
CE, FCC, RoHS
Note: Specifications are subject to change without notice.
Options
Optional devices can expand the capabilities and versatilities of your GV‐EV Controllers. Consult your sales representative for more
information.
GV‐Reader 1251 is a card reader that uses a 125 kHz frequency. It has both Wiegand and RS‐485 outputs that
can be connected to any standard access control panel.
GV‐Reader 1351 V2 is a card reader that uses a 13.56 MHz frequency. It has both Wiegand and RS‐485 outputs
that can be connected to any standard access control panel.
GV‐RK1352 is a card reader with keypad that uses a 13.56 MHz frequency. The reader has both Wiegand and
RS‐485 outputs that can be connected to any standard access control panel.
GV‐R1352 is a card reader that uses a 13.56 MHz frequency. The reader has both Wiegand and RS‐485 outputs
that can be connected to any standard access control panel.
GV‐DFR1352 is a card reader that uses a 13.56 MHz frequency. The reader has both Wiegand and RS‐485
outputs that can be connected to any standard access control panel.
The reader supports three operation modes: Fingerprint Only, Fingerprint + Card and Card Only. In Fingerprint
Only mode, the fingerprints are enrolled through GV‐ASManager. In Fingerprint + Card mode, the fingerprint
templates are stored on the user card. In Card Only mode, the users only need to swipe the card to be granted
access. Readers with optical and capacitance sensors are available.
GV‐CR420 is a card reader with a built‐in 4MP wide angle IP camera. The card reader recognizes identification
cards and transmits live view through network connection.
Cabinet
Only available for GV‐AS400 / 410 / 810 and GV‐EV48. With the cabinet, GV‐AS Controllers can be mounted
directly to a wall or recessed into the wall.
Two types of cabinet dimensions are available (W x H x D):
• 383.5 x 443.5 x 112.2 mm / 15.1 x 17.5 x 4.4 in
• 300 x 420 x 86 mm / 11.8 x 16.5 x 3.4 in
GV‐AS ID Cards and GV‐AS ID Tags are ideal for business and residential environment, where access control is
important for security reasons. 125 kHz and 13.56 MHz cards and tags are available.
Packing List
GV‐EV48 – 24 Floors / 48 Floors
Power Adaptor 12V DC / 3A
Power Cord
Battery Cable
Micro SD Card 2 GB
GV‐ASManager Software DVD
