Software License
Free License 32 channels from GV‐IP devices
Maximum License 32 channels from third‐party IP devices
Increment for Each License 1 to 32 third‐party IP cameras at an increment of 2
Optional Combinations N/A
Dongle Type Internal or external
Note:
1. The Maximum License is a paid service.
2. Product design and specifications are subject to change without notice.
Total Frame Rate and Max. No. of Channels Supported
For GV‐IP Camera (Dual Streams)
Dual Streams Intel Core i3 / i5
Video Resolution
Stream 1 (H.264) Stream 2 (H.264) Total FPS Full‐Frame Channels
D1 704 x 480 352 x 240 960 fps 32 ch
1.3 MP 1280 x 1024 320 x 256 960 fps 32 ch
2 MP 1920 x 1080 448 x 252 960 fps 32 ch
3 MP 2048 x 1536 320 x 240 640 fps 32 ch
5 MP 2560 x 1920 320 x 240 320 fps 32 ch
For GV‐Fisheyes Camera (De‐warping)
Intel Core i3 Intel Core i5
Video Resolution Single Stream (H.264)
Total FPS Full‐Frame Channels Total FPS Full‐Frame Channels
1.3 MP 1280 x 1024 120 fps 8 ch 180 fps 12 ch
2 MP 1440 x 1376 105 fps 7 ch 120 fps 8 ch
4 MP 2048 x 1944 45 fps 3 ch 60 fps 4 ch
5 MP 2560 x 1920 30 fps 3 ch 40 fps 4 ch
For Third‐Party IP Camera (Single Stream GPU Decode)
Intel Core i3 Intel Core i5
Video Resolution Single Stream (H.264)
Total FPS Full‐Frame Channels Total FPS Full‐Frame Channels
VGA 640 x 480 960 fps 32 ch 960 fps 32 ch
1 MP 1280 x 720 570 fps 19 ch 960 fps 32 ch
1.3 MP 1280 x 1024 570 fps 19 ch 960 fps 32 ch
2 MP 1920 x 1080 390 fps 13 ch 780 fps 26 ch
3 MP 2048 x 1536 540 fps 27 ch
4 MP 2048 x 1944 405 fps 27 ch
5 MP 2560 x 1920
Not supported
300 fps 30 ch
Options
GV‐Data Capture V3 Box
GV‐Data Capture V3 Box can integrate the GV‐Tower DVR/NVR System to an electronic POS system, while GV‐Data
Capture V3E Box can establish such integration through LAN or Internet.
GV‐Hub V2
An easy way for serial port extension. This hub can add 4 RS‐232/RS‐485 serial ports through the GV‐Tower DVR/NVR’s
USB port.
GV‐COM V2 This unit can add 1 RS‐232/RS‐485 serial port through the GV‐Tower DVR/NVR System's USB port.
GV‐IO Box (4 Ports)
GV‐IO Box 4 provides 4 inputs and 4 relay outputs, and supports both DC and AC output voltages. A USB port is also
provided for PC connection.
GV‐IO Box (8 Ports)
GV‐IO Box 8 provides 8 inputs and 8 relay outputs, and supports both DC and AC output voltages. A USB port is also
provided for PC connection.
GV‐IO Box (16 Ports)
GV‐IO Box 16 provides 16 inputs and 16 relay outputs, and supports both DC and AC output voltages. A USB port is also
provided for PC connection.
GV‐Joystick
GV‐Joystick facilitates the PTZ camera control. It can be either plugged into the GV‐Tower DVR/NVR System for
independent use or connected to GV‐Keyboard to empower the operation. However, this device can only work on
GV‐System version 8.2 or later.
GV‐Keyboard V3
The GV‐Keyboard V3 is designed to program and operate the system, and it can also be connected with PTZ cameras
directly for PTZ control.
