GV-Tower NVR System March 27, 2014
- 2 -
Specifications
Hardware
System
Intel Core i3 Processor
CPU
Intel Core i5 Processor (optional)
RAM 4 GB Dual Channels
No. of HDD 4 (3.5” HDD)
16 GB (DOM)
Internal Storage
32 GB (DOM) bundled with i5 Processor
OS 64‐bit Windows Embedded Standard 7
DirectX 11
Power 120 W, 100‐230 V, 47‐63 Hz
Ethernet RJ‐45, 10 / 100 / 1000 Mbps x 2
Video Output VGA and HDMI Connector
USB 2.0 Rear: 6 ports
Fan 7 cm (3 1/8") 2 units
Environment
Operating Temp. 0 ~ 45 °C / 32 ~ 113 °F
Humidity 0 ~ 80% RH (non‐condensing)
Physical
Color Black
Dimensions (W x H x D) 260 x 140 x 260 mm / 10.24 x 5.51 x 10.24 in
Net Weight 6.3 kg / 13.8 lb (± 1 kg / 2.2 lb)
Sensor and Alarm (Optional)
GV‐IO Box 4 Ports 4 inputs, 4 outputs
GV‐IO Box 8 Ports 8 inputs, 8 outputs
GV‐IO Box 16 Ports 16 inputs, 16 outputs
Software
Video and Audio
Model GV‐Tower NVR (GV) GV‐Tower NVR (3rd Party)
Video Input 32 channels 1, 2, 4, 6, 8, 10, 12, 16, 18, 20, 22, 24, 26, 28, 30, 32 channels
Audio Input 32 channels 1, 2, 4, 6, 8, 10, 12, 16, 18, 20, 22, 24, 26, 28, 30, 32 channels
Note: It is required to enable the dual‐stream function on GeoVision and third‐party IP cameras to have the maximum number of channels supported. For single
streaming third‐party IP cameras, please see "Total Frame Rate and Max. No. of Channels Supported" below.
Live View and Playback
Image Control Contrast / Brightness / Saturation / Hue
Recording Mode Round the Clock / Motion Detection / Sensor Detection / Pre & Post Recording / Schedule Recording
Pre Recording 1~ 45 min.
Instant Playback 10 sec. / 30 sec. / 1 min. / 5 min.
Watermark Supported
Searching and Playback
Search Method Date / Time / Camera / Event Type
Backup Type DVD+R (DL) / DVD‐R (DL) / DVD+R / DVD+RW / DVD‐R / DVD‐RW / CD‐R / CD‐RW
Note: For backup function, you need to connect an external USB DVD/CD burner.
Remote Monitoring
Monitoring Environment
Web browser (IE, Chrome, Firefox and Safari)
Mobile device (Android Smartphone and tablet; iPad, iPhone and iPod Touch)
Live View Max. 32–channel multi views (Up to 200 channels connection to GV‐Tower System)
Network Type LAN, WAN, Internet
System Monitoring and Recovery
Power Restoration Automatic restart after power outage
Monitoring
Two independent Watchdogs
(Hardware Watchdog + Software Watchdog)
Recovery Automatic system rebuild from internal hard disk.
Language
Type
Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Hebrew / Hungarian / Italian /
Japanese / Lithuanian / Norwegian / Polish / Portuguese / Romanian / Russian / Serbian / Simplified Chinese / Slovakian /
Slovenian / Spanish / Swedish / Thai / Traditional Chinese / Turkish
