GV-POE0400
4-Port 802.3at PoE Switch
5‐port 10/100BaseTX, 4‐port with PSE/Power over Ethernet
IEEE 802.3at Compliant (4 Ports at Full 15.4 W)
Max. 70 W power consumption
Auto‐MDI/MDI‐X
Auto‐Negotiation
Non‐Blocking
5" Metal Case of Palm Size
Up to 4 GV‐IP Cameras support
Introduction
The GV‐POE0400 is a 5‐port 10/100Base TX with 4 PSE/PoE ports Desktop PoE Fast Ethernet Switch. The switch supports IEEE 802.3at
Power over Ethernet standard, up to 30 W per port and maximum 70 W power consumption per system, and no special network cable
is required for connecting your powered devices (PD), such as IP cameras. The switch is designed for small network environment to
strengthen its network connection and efficiency.
Specifications
Ports
Number of Ports
5 ports (Fast Ethernet 10/100BaseTX, 4 ports with IEEE 802.3at PSE)
Performance
MAC Address
1 K
Buffer Memory
384 K bits
Transmission Method
Store and Forward
Transmission Media
10BaseT Cat. 5 UTP/STP
100BaseTX Cat. 5 UTP/STP
Filtering/Forwarding Rates
10 Mbps port ‐ 14,880 pps
100 Mbps port ‐ 148,800 pps
Mechanical Characteristics
LED Indicators
Per Port: Link/Act
PoE Act/Status
Power
Electrical Characteristics
Input
100 ~ 240 V/AC, 50 ~ 60 Hz
PoE Power
Output
IEEE 802.3at Compliant Voltage, Per Port Max. 30 watts
(4 Ports at Full 15.4 W / 2 Ports at Full 30 W)
Max. Power Consumption
70 W
General
Dimensions (H x W x D)
24 x 130 x 98 mm (0.94" x 5.11" x 3.86")
Weight
0.76 kg (1.68 lb)
Operating Temperature
0°C ~ 40°C (32°F ~ 104°F)
Storage Temperature
‐20°C ~ 90°C (‐4°F ~ 194°F)
Humidity
10 to 90% RH (non‐condensing)
Standards and Regulatory
Standards
IEEE‐802.3at PoE+ / PSE
IEEE 802.3 10BaseT
IEEE 802.3u 100BaseTX
IEEE 802.3x Flow Control
Regulatory
CE, FCC Class A
Note: Specifications are subject to change without notice.
GV-POE0400
December 13, 2013
