GeoVision WiFi USB adapter - Manual

WiFi USB adapter with a mini USB converter
Introduction
The WiFi USB Adaptor is designed to connect the GV IP devices to the wireless network. This product complies with IEEE 802.11 b/g/n
(Draft 3.0) standards for wireless networking. The WiFi USB Adaptor is a plug‐and‐play device; you don’t need to install any driver for
the device to work.
Compatible GV IP Devices
The WiFi USB Adaptor is compatible with the following hardware and firmware.
GV‐Video Server
 GV‐VS04H, GV‐VS04A (firmware V1.05 and later)
 GV‐VS12 (firmware V1.05 and later)
 GV‐VS11 (firmware V1.0 and later)
GV‐Compact DVR
 GV‐Compact DVR V2 (firmware V1.07 and later)
 GV‐Compact DVR V3 4‐CH (firmware V1.01 and later)
 GV‐Compact DVR V3 8‐CH (firmware V1.0 and later)
GV‐IP Cameras
 GV‐BX1200 Series (firmware V1.15 and later)
 GV‐BX1300 Series (firmware V1.15 and later)
 GV‐BX2400 Series (firmware V1.15 and later)
 GV‐BX3400 Series (firmware V1.15 and later)
 GV‐BX5300 Series (firmware V1.15 and later)
 GV‐MFD1501 Series (firmware V2.08 and later)
 GV‐MFD2401 Series (firmware V2.09 and later)
 GV‐MFD2501 Series (firmware V2.11 and later)
 GV‐MFD3401 Series (firmware V2.09 and later)
 GV‐MFD5301 Series (firmware V2.09 and later)
PN300, SQP133
(firmware V1.01 and later)
GV‐IP Decoder Box, GV‐Pad (firmware V1.02 and later)
Specifications
Network Standard IEEE 802.11 b/g/n (Draft 3.0)
Chipset Ralink RT3070
Host Interface USB 2.0 Backward Compatible (Standard‐A Type connector)
Operating Frequency 802.11b/g/n (2412 ~ 2484 MHz)
Dimensions (L x W x H) 15 x 15 x 155 mm(0.59 x 0.59 x 6.10”)
WPS Support Yes
Installation Guide Wi‐Fi USB Adapter
Wi-Fi USB Adapter March 26, 2014
