SPECIFICATIONS
Camera
Image Sensor 1/3” B/W progressive scan CMOS
Picture Elements 1280 (H) x 1024 (V)
Shutter Speed Automatic, Manual (1/500 ~ 1/8000 sec)
White Balance Automatic, Manual (2800K ~ 8500K)
S/N Ratio 50 dB
Max. Speed 120 km/h (75 mph)
Lens
Megapixel 1.3MP
Lens Type Varifocal
Focal Length 5 ~ 50 mm
Maximum Aperture F/1.6
Mount CS
Image Format 1/3”
Focus Manual (w / lock)
Zoom Manual (w / lock) Operation
Iris DC drive
IR Led Quantity 4 high power IR LEDs
IR Distance 6 m ~ 12 m
Max. Torque (Focus/ Zoom Screws) 0.049 N.m
Operation
Video Compression H.264, MJPEG
Video Stream Dual streams from H.264 and MJPEG
Frame Rate
30 fps at 1280 x 1024
* The frame rate and the performance may vary depending on the number of connections and data
bitrates (different scenes).
Image Setting Brightness, Contrast, Sharpness, Gamma, Image Orientation, Shutter Speed, Defog
Audio Compression G.711
Two‐way Audio Yes
Video Resolution
4:3 1280 x 960, 640 x 480, 320 x 240
16:9 1280 x 720, 640 x 360, 448 x 252 Main Stream
5:4 1280 x 1024, 640 x 512, 320 x 256
4:3 640 x 480, 320 x 240
16:9 640 x 360, 448 x 252 Sub Stream
5:4 640 x 512, 320 x 256
TV‐Out NTSC, PAL
Network
Interface 10/100 Base‐T Ethernet, RJ‐45 connector
Protocol
HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, RTSP, PSIA, SNMP, QoS
(DSCP) , ONVIF (Profile S)
Mechanical
Lens Mounting CS‐Mount
Temperature Detector Yes
Pan 0° ~ 330°
Camera Adjustment
Tilt 0° ~ 90°
Power PoE
Ethernet RJ‐45
Audio
1 In (externally connecting a microphone)
1 Out (Stereo phone jack, 3.5 mm / 0.14”)
Auto Iris DC drive
Connectors
TV‐Out BNC connector (640 x 480 resolution)
LED Indicator 1 LED (Status)
