GeoVision EBL1100 Series - Manual

GV-EBL1100 Series 1.3MP H.264 Low Lux WDR IR Bullet IP Camera
 1/3” progressive scan low lux CMOS
 Dual streams from H.264 and MJPEG
 Up to 30 fps at 1280 x 1024
 Intelligent IR
 Day and Night function (with removable IR‐cut filter)
 Wide Dynamic Range (WDR)
 Defog
 Vandal resistance (
IK10 for metal casing)
 Ingress protection (
IP67 )
 Motion detection
 Tampering alarm
 Text overlay
 Privacy mask
 IP address filtering
 DC 12V / PoE
 Megapixel lens
 Supports iPhone, iPad, Android & 3GPP
 31 languages on Web interface
 ONVIF (Profile S) conformant
Introduction
The Target Bullet Camera is a light‐weighted cameras designed for outdoor environments. It adheres to the IP67 standard and has full
protection against dust and jets of water. The camera offers an entry‐level surveillance solution with all the essential features and
excellent image quality.
Models
Model Iris Focal Length (mm) Maximum Aperture Image Format
GV‐EBL1100‐0F Fixed 3.6 F/1.8 1/2.7’’
GV‐EBL1100‐1F Fixed 6 F/1.8 1/2.7’’
Active Tampering Alarm
Tampered Focus Change Camera Shift
GV-EBL1100 Series March 18, 2014
- 1 -
